Volvo C40 I (2021-2024) left memory switch personal settings Wiring diagram
This page shows the only wiring diagram for the component.left memory switch personal settings, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left memory switch personal settings (1 of 1)
16 94/509
7 94/554
94/403
94/404
94/409
94/414
94/432
94/433
94/503
94/509
94/554
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL FUSE BOX
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
FRONT TUNNEL CONSOLE ILLUMINATION
FUSE 11
FUSE 2
GRN/WHT WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL SWITCH MODULE
LEFT FRONT DOOR PANEL ILLUMINATION
LEFT FRONT DOOR POCKET ILLUMINATION
LEFT FRONT GROUND ILLUMINATION
LEFT FRONT OUTER DOOR HANDLE
LEFT MEMORY SWITCH PERSONAL SETTINGS
LEFT REAR DOOR MODULE (RDM)
LEFT REAR OUTER DOOR HANDLE
OVERHEAD CONSOLE (OHC)
RED WIRE
STEERING WHEEL MODULE (SWM)
SUN SENSOR
TUNNEL CONSOLE STORAGE ILLUMINATION
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Instrument illumination circuit (1 of 3) -> LEFT MEMORY SWITCH PERSONAL SETTINGS
