Volvo C40 I (2021-2024) left headlight unit Wiring diagrams
This page contains all the electrical diagrams for the component. left headlight unit, in which he is found in the car Volvo C40 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left headlight unit (1 of 3)
94/304
94/404
94/414
94/434
94/503
BRN WIRE
BRN/GRY WIRE
CENTRAL ELECTRONIC MODULE (CEM) (LEFT END OF DASH)
GRN WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
INFOTAINMENT HEAD UNIT (IHU) (LOWER CENTER OF DASH)
LEFT HEADLAMP CONTROL MODULE (HCML)
LEFT HEADLIGHT UNIT
LEFT RESTRAINT MODULE (RML)
NCA WIRE
ON-BOARD CHARGER MODULE (OBC)
PNK WIRE
RIGHT HEADLAMP CONTROL MODULE (HCMR)
RIGHT HEADLIGHT UNIT
RIGHT RESTRAINT MODULE (RMR)
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
WIRELESS PHONE CHARGER (WPC)
YEL/VIO WIRE
Go to component -> Computer data lines circuit (4 of 5) -> LEFT HEADLIGHT UNIT
Wiring diagram left headlight unit (2 of 3)
94/301
94/304
94/512
94/601-1
AB PE
ACCELERATOR PEDAL SENSOR
BATTERY BACKED-UP SOUNDER (BBS)
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLIMATE COOLANT VALVE MODULE (CCVM)
ELECTRICAL VEHICLE INLET (EVI) AC/DC
ENGINE CONTROL MODULE (ECM)
ENGINE EXTERIOR SOUND MODULE (ESM)
GRN/YEL WIRE
HEATED RADAR COVER
HOOD LATCH
LEFT FRONT FOG LIGHT
LEFT HEADLIGHT UNIT
LEFT HORN
NCA WIRE
POWER OPERATED TAILGATE MODULE (POT)
RADIATOR COOLING FAN
RIGHT FRONT FOG LIGHT
RIGHT REAR TAIL LIGHT
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SODR)
RIGHT TRUNK LID TAIL LIGHT
WIPER MOTOR MODULE (WMM)
Go to component -> Ground distribution circuit (2 of 4) -> LEFT HEADLIGHT UNIT
Wiring diagram left headlight unit (3 of 3)
94/301
94/303
94/304
94/322
94/330
94/506
ACCELERATOR PEDAL SENSOR
BLK/VIO WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRAKE PEDAL SWITCH
BRN WIRE
CAPACITIVE OCCUPANT SENSOR (COS)
CENTRAL ELECTRONIC MODULE (CEM)
ENGINE CONTROL MODULE (ECM)
ENGINE FUSE BOX
EXTERIOR SOUND MODULE (ESM)
FROM ENGINE FUSE BOX (DIAGRAM 2 OF 8)
FROM FUSE 29 (DIAGRAM 2 OF 8)
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 19
FUSE 22
FUSE 27
FUSE 41
FUSE 42
IGNITION 15 RELAY
LEFT HEADLIGHT UNIT
LEFT REAR TAIL LIGHT
ON-BOARD CHARGER MODULE (OBC)
POWER STEERING CONTROL MODULE (PSCM)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT HEADLIGHT UNIT
RIGHT REAR TAIL LIGHT
SUPPLEMENTAL RESTRAINT SYSTEM MODULE (SRS)
TO POWER OUTLET RELAY (DIAGRAM 4 OF 8)
TRAILER MODULE (TRM)
Go to component -> Power distribution circuit (3 of 8) -> LEFT HEADLIGHT UNIT
