Volvo C40 I (2021-2024) left foldable seat relay Wiring diagram
This page shows the only wiring diagram for the component.left foldable seat relay, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left foldable seat relay (1 of 1)
94/403
94/434
BATTERY SAVER RELAY
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/BLU WIRE
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL FUSE BOX
COMFORT RELAY
ELECTRONIC GEAR SELECTOR MODULE (EGSM)
FROM FUSE 2 (DIAGRAM 1 OF 8)
FRONT WINDOWS WASHER PUMP RELAY
FUEL PUMP RELAY
FUSE 28
FUSE 33
FUSE 34
FUSE 55
FUSE 56
FUSE 80
FUSE 81
FUSE 83
FUSE 84
FUSE 85
FUSE 87
GRY/ORG WIRE
LEFT FOLDABLE SEAT RELAY
OVERHEAD CONSOLE (OHC)
REAR WINDOW DEFROSTER RELAY
REAR WINDOWS WASHER PUMP RELAY
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOLDABLE SEAT RELAY
TO CENTRAL FUSE BOX (DIAGRAM 6 OF 8)
TO IGNITION EXTENDED RELAY (DIAGRAM 6 OF 8)
TO IHU USB PORT (DIAGRAM 8 OF 8)
TO POWER OPERATED TAILGATE SWITCH (DIAGRAM 6 OF 8)
TO WIRELESS PHONE CHARGER (WPC) (DIAGRAM 8 OF 8)
WIDE ANGLE VISION MODULE (WAM)
Go to component -> Power distribution circuit (5 of 8) -> LEFT FOLDABLE SEAT RELAY
