Volvo C40 I (2021-2024) left dashboard air duct temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.left dashboard air duct temperature sensor, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left dashboard air duct temperature sensor (1 of 1)
94/403
94/404
94/409
94/414
94/505
94/701
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRY WIRE
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE SWITCH MODULE (CCSM)
CLIMATE CONTROL MODULE (CCM)
COMPUTER DATA LINES SYSTEM
FRONT BLOWER MODULE
FRONT BLOWER MOTOR
GRN WIRE
HUMIDITY SENSOR
LEFT DASHBOARD AIR DUCT TEMPERATURE SENSOR
LEFT SEAT MODULE (SML)
RED WIRE
RED/ORG WIRE
RED/WHT WIRE
RIGHT DASHBOARD AIR DUCT TEMPERATURE SENSOR
RIGHT END OF DASH)
SEAT HEATING REAR MODULE (SHRM)
SEATS SYSTEM
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Automatic a/c circuit (1 of 6) -> LEFT DASHBOARD AIR DUCT TEMPERATURE SENSOR
