Volvo C40 I (2021-2024) left d-pillar headliner speaker Wiring diagrams
This page contains all the electrical diagrams for the component. left d-pillar headliner speaker, in which he is found in the car Volvo C40 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left d-pillar headliner speaker (1 of 2)
94/407
94/504
94/510
AUDIO CONTROL MODULE (AUD) (UNDER FRONT PASSENGER SEAT)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/VIO WIRE
LEFT D-PILLAR HEADLINER SPEAKER
LEFT FRONT MIDRANGE DOOR SPEAKER
LEFT STEERING WHEEL SWITCH MODULE (SWSM)
ORG/ WIRE
ORG/GRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT STEERING WHEEL SWITCH MODULE (SWSM)
SUBWOOFER
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Navigation circuit (3 of 4) -> LEFT D-PILLAR HEADLINER SPEAKER
Wiring diagram left d-pillar headliner speaker (2 of 2)
94/407
94/504
94/510
AUDIO CONTROL MODULE (AUD) (UNDER FRONT PASSENGER SEAT)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/VIO WIRE
LEFT D-PILLAR HEADLINER SPEAKER
LEFT FRONT MIDRANGE DOOR SPEAKER
LEFT STEERING WHEEL SWITCH MODULE (SWSM)
ORG/ WIRE
ORG/GRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT STEERING WHEEL SWITCH MODULE (SWSM)
SUBWOOFER
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Radio circuit (3 of 4) -> LEFT D-PILLAR HEADLINER SPEAKER
