Volvo C40 I (2021-2024) headlights washer fluid pump Wiring diagrams
This page contains all the electrical diagrams for the component. headlights washer fluid pump, in which he is found in the car Volvo C40 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram headlights washer fluid pump (1 of 2)
94/403
94/514
AIR CONDITIONING COMPRESSOR MODULE A (ACCA)
AUDIO CONTROL MODULE (AUD)
BATTERY MONITORING SENSOR (BMS)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
COMPARTMENT COOLANT PUMP
ELECTRIC DRIVETRAIN COOLANT PUMP
ELECTRICAL EXPANSION VALVE (EXV)
HEADLIGHTS WASHER FLUID PUMP
HIGH VOLTAGE BATTERY (COMPLETE)
HIGH VOLTAGE BATTERY COOLANT FLUID PUMP
HIGH VOLTAGE COOLANT HEATER A (HVHA)
LEFT RESTRAINT MODULE (RML)
ORG/BLK WIRE
ORG/YEL WIRE
OUTSIDE HEAT EXCHANGER VALVE (OHXV)
POWER STEERING CONTROL MODULE (PSCM)
REAR SEAT HEATING MODULE (SHRM)
RIGHT HEADLIGHT UNIT
RIGHT HORN
RIGHT RESTRAINT MODULE (RMR)
WASHER FLUID LEVEL SENSOR
Go to component -> Ground distribution circuit (4 of 4) -> HEADLIGHTS WASHER FLUID PUMP
Wiring diagram headlights washer fluid pump (2 of 2)
15 94/303
94/304
94/701
BLK WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/YEL WIRE
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL FUSE BOX
COMPUTER DATA LINES SYSTEM
ENGINE FUSE BOX
FUSE 2
FUSE 28
FUSE 31
FUSE 55
FUSE 83
GRN WIRE
HEADLIGHTS WASHER FLUID PUMP
HOT AT ALL TIMES
HOT W/ BATTERY SAVER RELAY ENERGIZED
INTERIOR REAR VIEW MIRROR MODULE (IRMM)
RAIN, LIGHT SENSOR (RLSM)
RED WIRE
RED/BLK WIRE
WASHER FLUID LEVEL SENSOR
WHT WIRE
WHT/ORG WIRE
WIPER MOTOR MODULE (WMM)
YEL/BLK WIRE
Go to component -> Wiper/washer circuit -> HEADLIGHTS WASHER FLUID PUMP
