Volvo C40 I (2021-2024) camera heater Wiring diagram
This page shows the only wiring diagram for the component.camera heater, which is found in the car Volvo C40 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram camera heater (1 of 1)
94/304
94/403
94/512
94/701
ACTIVE SAFETY DOMAIN MASTER (ASDM)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN/GRY WIRE
BRN/WHT WIRE
CAMERA HEATER
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL FUSE BOX
COMPUTER DATA LINES SYSTEM
FORWARD LOOKING RADAR (FLR)
FUSE 15
FUSE 67
FUSE 85
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HEATED RADAR COVER
HOT AT ALL TIMES
HOT W/ BATTERY SAVER RELAY ENERGIZED
HOT W/ IGNITION EXTENDED RELAY ENERGIZED
NAVIGATION SYSTEM
PNK WIRE
RED WIRE
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/ORG WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Collision avoidance circuit -> CAMERA HEATER
