Central locking circuit for Volvo C30 I facelift (2010-2013)

2 64/47 64/43 64/662 8 6 7 5 AJAR SW 9 64/47 AJAR SW BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU/RED WIRE BRN/WHT WIRE CL UNL COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT DISTRIBUTION FUSE FUSE FUSE BOX (LEFT SIDE OF ENGINE COMPT) GRN/BLU WIRE GRN/RED WIRE GRN/YEL WIRE GRY/RED WIRE HOT AT ALL TIMES LOCK ORG/ WIRE ORG/WHT WIRE PASSENGER DOOR CENTRAL LOCKING SWITCH PASSENGER DOOR POWER WINDOW SWITCH PASSENGER'S DOOR LOCK UNIT (REAR OF PASSENGER'S FRONT DOOR) PASSENGER'S DOOR MODULE (CENTER OF PASSENGER'S FRONT DOOR) RED/BLU WIRE RED/ORG WIRE RED/YEL WIRE RIGHT REAR DOOR LOCK UNIT UN LOCK WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE

2 64/45 2 64/48 64/41 64/43 64/48 9 64/45 AJAR SW AJAR SW 1 6 5 7 BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/RED WIRE BRN/ORG WIRE CEM CENTER REAR OF TRUNK LID/TAILGATE) CENTRAL ELECTRONIC MODULE (BEHIND RIGHT SIDE OF DASH) CL UNL COMPUTER DATA LINES SYSTEM DRIVER'S DOOR CENTRAL LOCKING SWITCH DRIVER'S DOOR LOCK UNIT (REAR OF DRIVER'S FRONT DOOR) DRIVER'S DOOR MODULE (CENTER OF DRIVER'S FRONT DOOR) FUEL FILLER COVER LOCK MOTOR (RIGHT SIDE OF LUGGAGE COMPT) FUEL LID SWITCH LIGHTS SWITCH MODULE (LSM) FUSE FUSE FUSE GRN/BLK WIRE GRY/RED WIRE KEYLESS VEHICLE MODULE (KVM) (UNDER DRIVER'S SEAT) LEFT REAR DOOR LOCK UNIT LEFT REAR DOOR MODULE LOCK ORG/ WIRE ORG/BLU WIRE ORG/WHT WIRE ORG/YEL WIRE RED/BLU WIRE RED/ORG WIRE RED/YEL WIRE REMOTE RECEIVER MODULE (RRX) (FRONT CENTER OF ROOF) TRUNK LID/ TAILGATE LOCK UNIT TRUNK LID/ TAILGATE PRIVATE LOCK SWITCH TRUNK/ TAILGATE HANDLE SWITCH UN LOCK W/ MMS, RAIN SENSOR WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE
