Exterior lamps circuit, wagon for Volvo 960 I facelift (1994-1997)

1995 ONLY 6 7 8 9 10 BLK WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BRAKE LIGHT SWITCH (ON BRAKE PEDAL SUPPORT) BRN WIRE ENGINE COMPARTMENT RELAY/FUSE BOX FUSE 10 FUSE 11 FUSE 20 FUSE 21 FUSE 3 FUSE 8 GRN WIRE GRN/YEL WIRE GRY WIRE HEADLIGHTS SYSTEM HIGH MOUNT STOP LAMP HOT AT ALL TIMES HOT IN RUN W/ OVERLOAD RELAY ENERGIZED I/P FUSE BOX INTERIOR LIGHTS (RHEOSTAT) LEFT FRONT PARK/TURN LAMP LICENSE PLATE LIGHT LIGHT SWITCH MAIN FUSE BOX (NEAR BATTERY) MAIN HEADLIGHT RELAY (BEHIND DASH, LEFT OF STEERING COLUMN) PARK HEAD OFF PARKING LIGHT RELAY (ENGINE COMPT RELAY/FUSE BOX) PNK/BLK WIRE REAR BULB FAILURE WARNING SENSOR (LEFT REAR OF TRUNK/CARGO AREA) RED WIRE RED/WHT WIRE RIGHT FRONT PARK/TURN LAMP SHIFT INTERLOCK SYSTEM TERMINAL BLOCK (ENGINE COMPT. RELAY/FUSE BOX) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED (OR YEL) WIRE YEL/RED WIRE YEL/WHT WIRE

ANTI-THEFT SYSTEM BACK UP LAMP BACK-UP LAMPS CIRCUIT BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/YEL WIRE BRN/BLK WIRE BULB MALFUNCTION INDICATOR FUSE 17 FUSE 19 GRN WIRE GRY/BLK (OR BRN/PNK) WIRE GRY/BLK WIRE HAZARD FLASHER RELAY/ SWITCH ILLUM- INATION LAMP PR HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN RUN I/P FUSE BOX INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT TAILLIGHT ASSEMBLY LEFT TURN INDICATOR PARK/ STOP LAMP PNK/BLK WIRE REAR FOG LAMP REAR FOG LAMP TURN SIGNAL LAMP RED/BLK WIRE RED/WHT WIRE RIGHT TAILLIGHT ASSEMBLY RIGHT TURN INDICATOR SOLID STATE TURN SIGNAL LAMP PARK/ STOP LAMP TURN SIGNAL/ HIGH-LOW BEAM SWITCH VIO/WHT WIRE YEL/RED (OR YEL) WIRE YEL/RED WIRE YEL/WHT WIRE
