Volvo 960 I facelift (1994-1997) light bulb failure sensor indicator Wiring diagrams
This page contains all the electrical diagrams for the component. light bulb failure sensor indicator, in which he is found in the car Volvo 960 I facelift (1994-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram light bulb failure sensor indicator (1 of 2)
1996 ONLY
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLK WIRE
ENGINE COMPARTMENT RELAY/FUSE BOX
EXTERIOR LIGHTS SYSTEM (REAR BULB FAILURE WARNING SENSOR)
FOG LIGHT COUPLING BRIDGE
FOG LIGHT RELAY
FOGLIGHT SWITCH
FRONT
FRONT FRONT/REAR
FUSE
FUSE 10
FUSE 2
FUSE 24
FUSE 8
GRN WIRE
GRY (OR VIO/WHT) WIRE
HIGH BEAM INDICATOR
HOT AT ALL TIMES
I/P FUSE BOX
ILLUMINATION LAMP
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM (IGNITION SWITCH)
INTERIOR LIGHTS SYSTEM (RHEOSTAT)
LEFT FRONT FOG LIGHT
LEFT REAR FOG LAMP
LEFT TAILLIGHT ASSEMBLY
LEFT TAILLIGHT ASSEMBLY (SEDAN)
LEFT TAILLIGHT ASSEMBLY (WAGON) LEFT REAR FOG LAMP
LIGHT BULB FAILURE SENSOR INDICATOR
MAIN FUSE BOX (NEAR BATTERY)
OFF
ON INDICATOR
ON INDICATOR FRONT/ REAR
PARKING LIGHTS RELAY
PPL
PPL/BLK WIRE
REAR FOGLIGHTS INDICATOR
RED/BLK WIRE
RIGHT FRONT FOG LIGHT
RIGHT REAR FOG LAMP
RIGHT TAILLIGHT ASSEMBLY
RIGHT TAILLIGHT ASSEMBLY (SEDAN)
SEDAN
TERMINAL BLOCK (ENGINE COMPT. RELAY/FUSE BOX)
VIO WIRE
VIO/WHT WIRE
WAGON
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Headlamps/fog lamps circuit, canada (2 of 2) -> LIGHT BULB FAILURE SENSOR INDICATOR
Wiring diagram light bulb failure sensor indicator (2 of 2)
BLK WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN/BLK WIRE
ENGINE COMPARTMENT RELAY/FUSE BOX
EXTERIOR LIGHTS SYSTEM (REAR BULB FAILURE WARNING SENSOR)
FOG LIGHT COUPLING BRIDGE
FOG LIGHT RELAY
FOG LIGHT RELAY (USA)
FOGLIGHT SWITCH
FRONT
FRONT FRONT/REAR
FUSE
FUSE 2
FUSE 24
FUSE 8
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HIGH BEAM INDICATOR
HOT AT ALL TIMES
I/P FUSE BOX
ILLUMINATION LAMP
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM (IGNITION SWITCH)
INTERIOR LIGHTS SYSTEM (RHEOSTAT)
LEFT FRONT FOG LIGHT
LEFT REAR FOG LAMP
LEFT TAILLIGHT ASSEMBLY
LEFT TAILLIGHT ASSEMBLY (SEDAN)
LEFT TAILLIGHT ASSEMBLY (WAGON) LEFT REAR FOG LAMP
LIGHT BULB FAILURE SENSOR INDICATOR
MAIN FUSE BOX (NEAR BATTERY)
OFF
ON INDICATOR
ON INDICATOR FRONT/ REAR
PPL
PPL/BLK WIRE
REAR FOGLIGHTS INDICATOR
RED/BLK WIRE
RIGHT FRONT FOG LIGHT
RIGHT REAR FOG LAMP
RIGHT TAILLIGHT ASSEMBLY
RIGHT TAILLIGHT ASSEMBLY (SEDAN)
SEDAN
VIO WIRE
VIO/WHT WIRE
WAGON
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Headlamps/fog lamps circuit, usa (2 of 2) -> LIGHT BULB FAILURE SENSOR INDICATOR
