Volvo 960 I facelift (1994-1997) left front heated seat switch right front heated seat switch Wiring diagram

4-PIN ACCESSORY CONNECTOR (RIGHT SIDE OF I/P) BLK WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLK WIRE CIGAR LIGHTER CIRCUIT BREAKER 2 FUSE 11 ECC OPERATING SOLENOIDS, BLOWER MOTOR, ECC CONTROL MODULE, MCC CONTROL MODULE ENGINE COMPARTMENT RELAY/FUSE BOX FOGLIGHT RELAY FROM ENGINE COMPARTMENT RELAY/FUSE BOX FUSE 1 (SCHEMATIC 1 OF 2) FROM I/P FUSE BOX FUSE 16 (SCHEMATIC 1 OF 2) FROM I/P FUSE BOX FUSE 4 (SCHEMATIC 1 OF 2) FROM MAIN FUSE BOX FUSE 1 (SCHEMATIC 1 OF 2) FROM MAIN FUSE BOX FUSE 2 (SCHEMATIC 1 OF 2) FROM MAIN FUSE BOX FUSE 3 (SCHEMATIC 1 OF 2) FRONT FOGLIGHTS, FOGLIGHT SWITCH FUEL PUMP RELAY, OBD DATA LINK CONNECTOR, MOTRONIC MFI CONTROL MODULE FUSE 12 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 21 FUSE 20 FUSE 19 FUSE 22 FUSE 23 FUSE 6 FUSE 5 SPARE FUSE 7 FUSE 8 FUSE 9 FUSE 10 FUSE 9 SPARE GRN/BRN WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND HIGH BEAM RHEOSTAT GRY/RED WIRE HEADLIGHTS SYSTEM (MAIN HEADLIGHT RELAY) I/P FUSE BOX IGNITION SWITCH INSTRUMENT CLUSTER INSTRUMENT CLUSTER, ALARM RELAY INSTRUMENT CLUSTER, RIGHT HEADLIGHT LEFT HEADLIGHT, FOGLIGHT RELAY (USA) KEY IN KEY-IN IGNITION SWITCH LEFT FRONT HEATED SEAT SWITCH RIGHT FRONT HEATED SEAT SWITCH LIGHT SWITCH MODE SELECTOR, DELAYED ACTION INSIDE LIGHTING/ CENTRAL LOCK RELAY OFF ORG/ WIRE ORG/WHT WIRE OVERLOAD OVERLOAD RELAY +X PNK WIRE PNK/WHT WIRE PPL RADIO, REMOTE CONTROL CENTRAL LOCKING, CAR ALARM CONTROL MODULE RED WIRE RED/BLK WIRE RELAY RHEOSTAT RIGHT HEADLIGHT LEFT HEADLIGHT SEAT BELT REMINDER/ IGNITION KEY WARNING SRS SENSOR UNIT START MOTOR RELAY (W/O ANTI- THEFT), SERVICE SOCKET, ALARM RELAY (W/ ANTI-THEFT) WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE
