Volvo 960 I facelift (1994-1997) i/p fuse box wiring diagrams

i/p fuse box wiring diagram (1 of 29)

ABS CONTROL MODULE (RIGHT SIDE OF DASH, NEAR KICK PANEL) ABS HYDRAULIC UNIT (RIGHT FRONT OF ENGINE COMPARTMENT) ABS INDICATOR BLK WIRE BLU WIRE BLU/PNK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) BRN WIRE BRN/WHT WIRE FUSE 12 FUSE 3 FUSE 5 GENERATOR GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE HOT AT ALL TIMES I/P FUSE BOX IGNITION SWITCH INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT FRONT ABS SENSOR MAIN FUSE BOX (NEAR BATTERY) NCA WIRE OFF ACCY ORG/ WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT ABS SENSOR RUN WIRE S+ S- SPEEDOMETER TERMINAL BLOCK (PARKING BRAKE BRACKET) VEHICLE SPEED AND ABS SENSOR (AT REAR DIFFERENTIAL) YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Anti-lock brake circuits -> I/P FUSE BOX

i/p fuse box wiring diagram (2 of 29)

ALARM HORN (RIGHT REAR OF ENGINE COMPT) ALARM RELAY ALARM WARNING LED ALARM WARNING LED (TOP RIGHT OF I/P) ATR ATR RH BLK WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE CENTER CONSOLE RELAY BLOCK DELAYED ACTION INSIDE LIGHTING/ CENTRAL LOCK RELAY (CENTER CONSOLE RELAY BLOCK) ECC CONTROL MODULE ECC SOLAR SENSOR/ ALARM WARNING LED (TOP RIGHT OF I/P) ELECTRONIC CLIMATE CONTROL ONLY EXTERIOR LIGHTS SYSTEM (TURN- SIGNAL LAMPS) FH AL FUSE 17 FUSE 14 FUSE 13 FUSE 2 FUSE 9 LOCK GRN WIRE GRN/RED WIRE GROUND CONNECTION (CENTER CONSOLE RELAY BLOCK) HOOD ALARM SWITCH (LEFT FRONT OF ENGINE COMPT) HOT AT ALL TIMES HOT IN RUN W/ OVERLOAD RELAY ENERGIZED I/P FUSE BOX IGNITION SWITCH INTERIOR LIGHTS SYSTEM (COURTESY LAMPS) INTERIOR LIGHTS SYSTEM (COURTESY LIGHTS) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LOAD AREA ROOF LIGHT LOCK NCA WIRE PNK PNK START MOTOR RELAY (ENGINE COMPT FUSE/RELAY BOX) WIRE PNK SERVICE SOCKET WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH RUN WIRE SEDAN SOLID STATE TAILGATE DOOR SWITCH TERMINAL BLOCK (PARKING BRAKE BRACKET) TRUNK LOCK W/ ELECTRONIC CLIMATE CONTROL W/O ELECTRONIC CLIMATE CONTROL WAGON WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/WHT WIRE

Go to component -> Anti-theft circuit -> I/P FUSE BOX

i/p fuse box wiring diagram (3 of 29)

2 13 (1995) (1996-97) BLK WIRE BLU/GRY WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) BRAKE PEDAL SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) CLUTCH PEDAL SWITCH (ON BRACKET, ABOVE CLUTCH PEDAL) CRUISE CONTROL MODULE (CENTER CONSOLE RELAY BLOCK) CRUISE CONTROL SWITCH CRUISE CONTROL VACUUM PUMP (FRONT OF LEFT SHOCK TOWER) DEC FUSE 19 FUSE 3 GRN/BRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT WITH OVERLOAD RELAY ENERGIZED I/P FUSE BOX INSTRUMENT CLUSTER NCA WIRE OFF ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE PNK/BLK WIRE RES+ SPEEDOMETER START MOTOR RELAY TERMINAL BLOCK 19 (BELOW CENTER CONSOLE) VIO/WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BRN WIRE YEL/GRY (OR GRN/ORG) WIRE YEL/GRY WIRE YEL/WHT WIRE

Go to component -> Cruise control circuit -> I/P FUSE BOX

i/p fuse box wiring diagram (4 of 29)

BLK WIRE BLU WIRE BLU/GRN WIRE BRN/BLK WIRE DEFOGGER ON INDICATOR FUSE 1 FUSE 21 GRN WIRE GROUND CONNECTION (CENTRAL RELAY MODULE) HEATED REAR WINDOW/DOOR MIRRORS SWITCH HOT AT ALL TIMES HOT IN RUN W/ OVERLOAD RELAY ENERGIZED I/P FUSE BOX ILLUMINATION LAMP INSTRUMENT CLUSTER SYSTEM (RHEOSTAT) LEFT POWER DOOR MIRROR LEFT POWER DOOR MIRROR HEATING ELEMENT REAR WINDOW HEATING ELEMENT REAR WINDOW/ DOOR MIRROR HEATING RELAY (CENTER CONSOLE RELAY BLOCK) RIGHT POWER DOOR MIRROR RIGHT POWER DOOR MIRROR HEATING ELEMENT WHT WIRE YEL WIRE YEL/BLK WIRE YEL/GRY WIRE

Go to component -> Defogger circuit -> I/P FUSE BOX

i/p fuse box wiring diagram (5 of 29)

BLK WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BRAKE LIGHT SWITCH (ON BRAKE PEDAL SUPPORT) BRN WIRE ENGINE COMPARTMENT RELAY/FUSE BOX FUSE 10 FUSE 11 FUSE 20 FUSE 21 FUSE 3 FUSE 8 GRN WIRE GRN/YEL WIRE GRY WIRE HEADLIGHTS SYSTEM HIGH MOUNT STOP LAMP HOT AT ALL TIMES HOT IN RUN W/ OVERLOAD RELAY ENERGIZED I/P FUSE BOX INTERIOR LIGHTS (RHEOSTAT) LEFT FRONT PARK/TURN LAMP LICENSE PLATE LIGHT LIGHT SWITCH MAIN FUSE BOX (NEAR BATTERY) MAIN HEADLIGHT RELAY (BEHIND DASH, LEFT OF STEERING COLUMN) PARK HEAD OFF PARKING LIGHT RELAY (ENGINE COMPT RELAY/FUSE BOX) PNK/BLK WIRE REAR BULB FAILURE WARNING SENSOR (LEFT REAR OF TRUNK/CARGO AREA) RED WIRE RED/WHT (OR RED) WIRE RED/WHT WIRE RIGHT FRONT PARK/TURN LAMP SHIFT INTERLOCK SYSTEM TERMINAL BLOCK (ENGINE COMPT. RELAY/FUSE BOX) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED (OR YEL) WIRE YEL/RED WIRE YEL/WHT (OR BRN/WHT) WIRE YEL/WHT WIRE

Go to component -> Exterior lamps circuit, sedan (1 of 2) -> I/P FUSE BOX

i/p fuse box wiring diagram (6 of 29)

ANTI-THEFT SYSTEM BACK UP LAMP BACK-UP LAMPS CIRCUIT BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/YEL WIRE BRN/BLK WIRE BULB MALFUNCTION INDICATOR FUSE 17 FUSE 19 GRN WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE HAZARD FLASHER RELAY/ SWITCH ILLUM- INATION LAMP PR HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN RUN I/P FUSE BOX INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT TAILLIGHT ASSEMBLY LEFT TURN INDICATOR PARK LAMP PNK/BLK WIRE REAR FOG LAMP RED/BLK WIRE RED/WHT (OR RED) WIRE RED/WHT WIRE RIGHT TAILLIGHT ASSEMBLY RIGHT TURN INDICATOR SOLID STATE STOP LAMP STOP LAMP PARK LAMP TURN SIGNAL LAMP TURN SIGNAL/ HIGH-LOW BEAM SWITCH YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> Exterior lamps circuit, sedan (2 of 2) -> I/P FUSE BOX

i/p fuse box wiring diagram (7 of 29)

1995 ONLY 6 7 8 9 10 BLK WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BRAKE LIGHT SWITCH (ON BRAKE PEDAL SUPPORT) BRN WIRE ENGINE COMPARTMENT RELAY/FUSE BOX FUSE 10 FUSE 11 FUSE 20 FUSE 21 FUSE 3 FUSE 8 GRN WIRE GRN/YEL WIRE GRY WIRE HEADLIGHTS SYSTEM HIGH MOUNT STOP LAMP HOT AT ALL TIMES HOT IN RUN W/ OVERLOAD RELAY ENERGIZED I/P FUSE BOX INTERIOR LIGHTS (RHEOSTAT) LEFT FRONT PARK/TURN LAMP LICENSE PLATE LIGHT LIGHT SWITCH MAIN FUSE BOX (NEAR BATTERY) MAIN HEADLIGHT RELAY (BEHIND DASH, LEFT OF STEERING COLUMN) PARK HEAD OFF PARKING LIGHT RELAY (ENGINE COMPT RELAY/FUSE BOX) PNK/BLK WIRE REAR BULB FAILURE WARNING SENSOR (LEFT REAR OF TRUNK/CARGO AREA) RED WIRE RED/WHT WIRE RIGHT FRONT PARK/TURN LAMP SHIFT INTERLOCK SYSTEM TERMINAL BLOCK (ENGINE COMPT. RELAY/FUSE BOX) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED (OR YEL) WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> Exterior lamps circuit, wagon (1 of 2) -> I/P FUSE BOX

i/p fuse box wiring diagram (8 of 29)

ANTI-THEFT SYSTEM BACK UP LAMP BACK-UP LAMPS CIRCUIT BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/YEL WIRE BRN/BLK WIRE BULB MALFUNCTION INDICATOR FUSE 17 FUSE 19 GRN WIRE GRY/BLK (OR BRN/PNK) WIRE GRY/BLK WIRE HAZARD FLASHER RELAY/ SWITCH ILLUM- INATION LAMP PR HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN RUN I/P FUSE BOX INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT TAILLIGHT ASSEMBLY LEFT TURN INDICATOR PARK/ STOP LAMP PNK/BLK WIRE REAR FOG LAMP REAR FOG LAMP TURN SIGNAL LAMP RED/BLK WIRE RED/WHT WIRE RIGHT TAILLIGHT ASSEMBLY RIGHT TURN INDICATOR SOLID STATE TURN SIGNAL LAMP PARK/ STOP LAMP TURN SIGNAL/ HIGH-LOW BEAM SWITCH VIO/WHT WIRE YEL/RED (OR YEL) WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> Exterior lamps circuit, wagon (2 of 2) -> I/P FUSE BOX

i/p fuse box wiring diagram (9 of 29)

1996 ONLY BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE ENGINE COMPARTMENT RELAY/FUSE BOX EXC USA/ CANADA FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 15 FUSE 20 FUSE 3 FUSE 8 GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRN/YEL WIRE HEAD HI LO HOT AT ALL TIMES HOT IN RUN W/ OVERLOAD RELAY ENERGIZED I/P FUSE BOX ILLUMINATION LAMPS INTERIOR LIGHTS SYSTEM (RHEOSTAT) LEFT HEADLIGHT LIGHT SWITCH PR LO HI MAIN FUSE BOX (NEAR BATTERY) MAIN HEADLIGHT RELAY (BEHIND DASH, LEFT OF STEERING COLUMN) OFF PARK PPL/BLK WIRE RIGHT HEADLIGHT SOLID STATE TURN SIGNAL/ HIGH-LOW BEAM SWITCH USA CANADA YEL/RED WIRE

Go to component -> Headlamps/fog lamps circuit, canada (1 of 2) -> I/P FUSE BOX

i/p fuse box wiring diagram (10 of 29)

1996 ONLY BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLK WIRE ENGINE COMPARTMENT RELAY/FUSE BOX EXTERIOR LIGHTS SYSTEM (REAR BULB FAILURE WARNING SENSOR) FOG LIGHT COUPLING BRIDGE FOG LIGHT RELAY FOGLIGHT SWITCH FRONT FRONT FRONT/REAR FUSE FUSE 10 FUSE 2 FUSE 24 FUSE 8 GRN WIRE GRY (OR VIO/WHT) WIRE HIGH BEAM INDICATOR HOT AT ALL TIMES I/P FUSE BOX ILLUMINATION LAMP INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM (IGNITION SWITCH) INTERIOR LIGHTS SYSTEM (RHEOSTAT) LEFT FRONT FOG LIGHT LEFT REAR FOG LAMP LEFT TAILLIGHT ASSEMBLY LEFT TAILLIGHT ASSEMBLY (SEDAN) LEFT TAILLIGHT ASSEMBLY (WAGON) LEFT REAR FOG LAMP LIGHT BULB FAILURE SENSOR INDICATOR MAIN FUSE BOX (NEAR BATTERY) OFF ON INDICATOR ON INDICATOR FRONT/ REAR PARKING LIGHTS RELAY PPL PPL/BLK WIRE REAR FOGLIGHTS INDICATOR RED/BLK WIRE RIGHT FRONT FOG LIGHT RIGHT REAR FOG LAMP RIGHT TAILLIGHT ASSEMBLY RIGHT TAILLIGHT ASSEMBLY (SEDAN) SEDAN TERMINAL BLOCK (ENGINE COMPT. RELAY/FUSE BOX) VIO WIRE VIO/WHT WIRE WAGON WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BRN WIRE YEL/WHT WIRE

Go to component -> Headlamps/fog lamps circuit, canada (2 of 2) -> I/P FUSE BOX
