Volvo 960 I facelift (1994-1997) hot in run or acc, w/ overload relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot in run or acc, w/ overload relay energized, which is found in the car Volvo 960 I facelift (1994-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in run or acc, w/ overload relay energized (1 of 1)
AMBIENT TEMPERATURE SENSOR
BLK WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN/BLK WIRE
CIGAR LIGHTER ILLUMINATION
CLOCK/RHEOSTAT SWITCH
ECC CONTROL MODULE
FOG LIGHT SWITCH
FRONT ASHTRAY ILLUMINATION
FUSE 8
GEAR SELECTOR ILLUMINATION
GRN/GRY WIRE
GROUND CONNECTION (CENTER CONSOLE RELAY BLOCK)
HAZARD WARNING SWITCH
HEATED REAR WINDOW/DOOR MIRROR SWITCH
HOT IN RUN OR ACC, W/ OVERLOAD RELAY ENERGIZED
I/P FUSE BOX
ILLUMINATION
INSTRUMENT CLUSTER
LIGHT SWITCH
MCC CONTROL MODULE
MODE SELECTOR
ORG/ WIRE
POWER SUNROOF SWITCH
RADIO
REAR ASHTRAY ILLUMINATION
RHEOSTAT
SEAT HEATER SWITCH
TERMINAL BLOCK (PARKING BRAKE BRACKET)
Go to component -> Instrument illumination circuit -> HOT IN RUN OR ACC, W/ OVERLOAD RELAY ENERGIZED
