Exterior lamps circuit, wagon for Volvo 850 I (1991-1997)

1995 LATE PRODUCTION, 1996, 1997 1995 EARLY PRODUCTION BATTERY BLK WIRE BLU WIRE BLU/GRN WIRE BLU/YEL WIRE CENTRAL ELECTRICAL UNIT (LEFT REAR OF ENGINE COMPT) CONNECTOR FUSE 12 FUSE 23 FUSE 24 FUSE 28 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE HEADLIGHTS SYSTEM HIGH MOUNT STOP LAMP HOT AT ALL TIMES IGNITION SWITCH INTERIOR LIGHTS (RHEOSTAT) LEFT FRONT PARK/TURN LAMP LEFT SIDE TURN SIGNAL LAMP LICENSE PLATE LIGHT LIGHT SWITCH MAIN HEADLIGHT RELAY/BULB FAILURE WARNING SENSOR OFF PARK HEAD OFF POWER GROUND CONNECTOR REAR BULB FAILURE SENSOR (LEFT REAR OF TRUNK/CARGO AREA) RED WIRE RED/WHT WIRE RIGHT FRONT PARK/TURN LAMP RIGHT SIDE TURN SIGNAL LAMP RUN WIRE SHIFT INTERLOCK SYSTEM STOP LIGHT SWITCH (ON BRAKE PEDAL SUPPORT) WHT WIRE YEL WIRE YEL/BRN WIRE YEL/GRY WIRE

1995 EARLY PRODUCTION 1995 ONLY ANTI-THEFT SYSTEM BACK UP LAMP BACK-UP LAMPS CIRCUIT BLK WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BULB MALFUNCTION INDICATOR CENTRAL ELECTRICAL UNIT (LEFT REAR OF ENGINE COMPT) FUSE 13 FUSE 27 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE GRY/WHT WIRE HAZARD FLASHER RELAY/ SWITCH ILLUM- INATION LAMP HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN RUN INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT LOWER TAILLIGHT ASSEMBLY LEFT TURN INDICATOR LEFT UPPER TAILLIGHT ASSEMBLY PARK LAMP PNK WIRE POWER GROUND CONNECTOR REAR FOG/ PARK LAMP RED WIRE RED/WHT WIRE RIGHT LOWER TAILLIGHT ASSEMBLY RIGHT TURN INDICATOR RIGHT UPPER TAILLIGHT ASSEMBLY SOLID STATE STOP LAMP TRAILER INDICATOR TURN SIGNAL LAMP TURN SIGNAL/ HIGH-LOW BEAM SWITCH VIO/WHT WIRE YEL/BRN WIRE YEL/GRY WIRE
