Volvo 850 I (1991-1997) power windows/power mirrors console switch assembly Wiring diagram
This page shows the only wiring diagram for the component.power windows/power mirrors console switch assembly, which is found in the car Volvo 850 I (1991-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power windows/power mirrors console switch assembly (1 of 1)
1 2 1995 MODELS 1996-97 MODELS
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CENTRAL ELECTRICAL UNIT (LEFT REAR OF ENGINE COMPT)
DEFOGGERS SYSTEM
FUSE 26
GRN/GRY WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HOT IN RUN
LEFT POWER DOOR MIRROR
LEFT POWER DOOR MIRROR HEATING ELEMENT
LEFT POWER DOOR MIRROR SWITCH
POWER WINDOWS/POWER MIRRORS CONSOLE SWITCH ASSEMBLY
RIGHT POWER DOOR MIRROR
RIGHT POWER DOOR MIRROR HEATING ELEMENT
RIGHT POWER DOOR MIRROR SWITCH
X-MOTOR
Y-MOTOR
YEL WIRE
YEL/RED WIRE
Go to component -> Power mirror circuit -> POWER WINDOWS/POWER MIRRORS CONSOLE SWITCH ASSEMBLY
