Volvo 850 I (1991-1997) main headlight relay/bulb failure warning sensor Wiring diagrams
This page contains all the electrical diagrams for the component. main headlight relay/bulb failure warning sensor, in which he is found in the car Volvo 850 I (1991-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram main headlight relay/bulb failure warning sensor (1 of 2)
1995 LATE PRODUCTION, 1996, 1997 1995 EARLY PRODUCTION
BATTERY
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
CENTRAL ELECTRICAL UNIT (LEFT REAR OF ENGINE COMPT)
CONNECTOR
FROM TRUNK LOCK (DIAGRAM 1 OF 2)
FUSE 12
FUSE 23
FUSE 24
FUSE 28
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
IGNITION SWITCH
INTERIOR LIGHTS (RHEOSTAT)
LEFT FRONT PARK/TURN LAMP
LEFT SIDE TURN SIGNAL LAMP
LICENSE PLATE LIGHT
LICENSE PLATE LIGHT (DIAGRAM 1 OF 2)
LIGHT SWITCH
MAIN HEADLIGHT RELAY/BULB FAILURE WARNING SENSOR
NCA WIRE
OFF
PARK HEAD OFF
POWER GROUND CONNECTOR
REAR BULB FAILURE WARNING SENSOR (LEFT REAR OF TRUNK/CARGO AREA)
RED WIRE
RED/WHT WIRE
RIGHT FRONT PARK/TURN LAMP
RIGHT SIDE TURN SIGNAL LAMP
RUN WIRE
SHIFT INTERLOCK SYSTEM
SPOILER HIGH- MOUNT STOP LAMP HIGH- MOUNT STOP LAMP
STOP LIGHT SWITCH (ON BRAKE PEDAL SUPPORT)
TRUNK LOCK
W/ REAR SPOILER
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component -> Exterior lamps circuit, sedan (1 of 2) -> MAIN HEADLIGHT RELAY/BULB FAILURE WARNING SENSOR
Wiring diagram main headlight relay/bulb failure warning sensor (2 of 2)
1995 LATE PRODUCTION, 1996, 1997 1995 EARLY PRODUCTION
BATTERY
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
CENTRAL ELECTRICAL UNIT (LEFT REAR OF ENGINE COMPT)
CONNECTOR
FUSE 12
FUSE 23
FUSE 24
FUSE 28
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
HEADLIGHTS SYSTEM
HIGH MOUNT STOP LAMP
HOT AT ALL TIMES
IGNITION SWITCH
INTERIOR LIGHTS (RHEOSTAT)
LEFT FRONT PARK/TURN LAMP
LEFT SIDE TURN SIGNAL LAMP
LICENSE PLATE LIGHT
LIGHT SWITCH
MAIN HEADLIGHT RELAY/BULB FAILURE WARNING SENSOR
OFF
PARK HEAD OFF
POWER GROUND CONNECTOR
REAR BULB FAILURE SENSOR (LEFT REAR OF TRUNK/CARGO AREA)
RED WIRE
RED/WHT WIRE
RIGHT FRONT PARK/TURN LAMP
RIGHT SIDE TURN SIGNAL LAMP
RUN WIRE
SHIFT INTERLOCK SYSTEM
STOP LIGHT SWITCH (ON BRAKE PEDAL SUPPORT)
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component -> Exterior lamps circuit, wagon (1 of 2) -> MAIN HEADLIGHT RELAY/BULB FAILURE WARNING SENSOR
