Supplemental restraints circuit for Volkswagen Touareg II (2010-2014)

Supplemental restraints circuit (1 of 3)

Touareg Volkswagen II (2010-2014): Supplemental restraints circuit (1 of 3)

Get access

AIR BAG CONTROL MODULE (UNDER CENTER CONSOLE) BLK WIRE BLK/BRN WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S HEAD CURTAIN AIR BAG IGNITER DRIVER'S KNEE AIR BAG IGNITER (IF EQUIPPED) DRIVER'S SEAT BELT SWITCH DRIVER'S SEAT POSITION SENSOR FRONT PASSENGER'S AIR BAG DEACTIVATION KEY SWITCH FRONT PASSENGER'S AIR BAG IGNITER 2 (BEHIND RIGHT SIDE OF DASH) FRONT PASSENGER'S HEAD CURTAIN AIR BAG IGNITER FRONT PASSENGER'S SEAT POSITION SENSOR FRONT PASSENGER'S SIDE REAR SEAT BELT TENSIONER IGNITER FUSE 14 FUSE PANEL C (RIGHT END OF DASH) GRN WIRE GRY WIRE GRY/RED WIRE HOT IN ON OR START NCA WIRE RED WIRE RED/WHT WIRE VIO WIRE WHT WIRE YEL WIRE

Supplemental restraints circuit (2 of 3)

Touareg Volkswagen II (2010-2014): Supplemental restraints circuit (2 of 3)

Get access

AIR BAG SPIRAL SPRING/RETURN SPRING W/ SLIP RING BATTERY INTERRUPT IGNITER BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN WIRE DRIVER SIDE REAR THORAX AIR BAG IGNITER DRIVER THORAX AIR BAG IGNITER FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP FRONT PASSENGER REAR THORAX AIR BAG IGNITER FRONT PASSENGER SEAT BELT SWITCH FRONT PASSENGER THORAX AIR BAG IGNITER GRN WIRE GRY WIRE NCA WIRE PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE PASSENGER OCCUPANT DETECTION SYSTEM PRESSURE SENSOR RED WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE (TOP OF STEERING COLUMN) VIO WIRE WHT WIRE YEL WIRE YEL/GRY WIRE

Supplemental restraints circuit (3 of 3)

Touareg Volkswagen II (2010-2014): Supplemental restraints circuit (3 of 3)

Get access

AIR BAG CONTROL MODULE (UNDER CENTER CONSOLE) AIR BAG INDICATOR LAMP BATTERY REGULATION CONTROL MODULE (HYBRID) (LEFT FRONT OF HYBRID BATTERY UNIT) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM DRIVER BELT FORCE LIMITER DRIVER FRONT AIR BAG CRASH SENSOR (LEFT FRONT OF VEHICLE) DRIVER SIDE AIR BAG CRASH SENSOR (IN DRIVER DOOR) DRIVER SIDE REAR SEAT BELT TENSIONER IGNITER DRIVER SIDE REAR SIDE AIR BAG CRASH SENSOR (ON LEFT "C" PILLAR) FRONT PASSENGER AIR BAG CRASH SENSOR (RIGHT FRONT OF VEHICLE) FRONT PASSENGER BELT FORCE LIMITER FRONT PASSENGER SIDE AIR BAG CRASH SENSOR (IN PASSENGER DOOR) GRN WIRE INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE ORG/BLK WIRE ORG/BRN WIRE ORG/VIO WIRE PASSENGER SIDE REAR SIDE AIR BAG CRASH SENSOR (ON RIGHT "C" PILLAR) RED WIRE SEAT BELT INDICATOR LAMP LAMP SYSTEM VIO WIRE WHT WIRE YEL WIRE YEL/GRY WIRE
