Shift interlock circuit for Volkswagen Touareg II (2010-2014)
Shift interlock circuit
3.0L TURBO DIESEL
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRAKE LAMP SWITCH
BRN WIRE
BRN/VIO WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (IN RIGHT PLENUM)
EXCEPT 3.0L TURBO DIESEL
FUSE 23 (LEFT END OF DASH)
FUSE PANEL B
GRY/WHT WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE PANEL FUSE 10
IGNITION/STARTER SWITCH
MULTI-FUNCTION TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED/GRN WIRE
RED/YEL WIRE
TIPTRONIC SWITCH (UNDER TRANSMISSION SELECTOR LEVER)
TRANSMISSION CONTROL MODULE
TRANSMISSION RANGE (TR) DISPLAY
WHT/BLU WIRE
YEL/BLK WIRE
