Tv tuner circuit for Volkswagen Touareg II (2010-2014)
Tv tuner circuit
BRN WIRE
COMPUTER DATA LINES SYSTEM
DVD CHARGER
GRY/VIO WIRE
HOT AT ALL TIMES FUSE PANEL C FUSE (RIGHT END OF DASH)
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT ANTENNA MODULE
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RED/YEL WIRE
RIGHT ANTENNA MODULE
TV ANTENNA
TV TUNER
W/ DVD CHANGER
W/O DVD CHANGER
