Radio circuit, with navigation without amplifier for Volkswagen Touareg II (2010-2014)
Radio circuit, with navigation without amplifier (1 of 2)
ANTENNA
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CD/DVD CHANGER CIRCUIT
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA (IF EQUIPPED)
EXTERNAL AUDIO SOURCE CONNECTION
FRONT INFORMATION DISPLAY CONTROL HEAD
FUSE 47
FUSE 51
FUSE PANEL
GPS ANTENNA
GRN WIRE
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT ANTENNA MODULE
LEFT FRONT MICROPHONE
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RADIO ANTENNA 2
RED/YEL WIRE
RIGHT ANTENNA MODULE
RIGHT END OF DASH)
ROOF ANTENNA
SATELLITE TUNER ANTENNA
VIO WIRE
WHT WIRE
YEL WIRE
Radio circuit, with navigation without amplifier (2 of 2)
BRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
GRY/VIO WIRE
LEFT FRONT BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR BASS SPEAKER
LEFT REAR TREBLE SPEAKER
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/ WIRE
RADIO/NAVIGATION CONTROL MODULE
RED/YEL WIRE
RIGHT END OF DASH)
RIGHT FRONT BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR BASS SPEAKER
RIGHT REAR TREBLE SPEAKER
VIO WIRE
WHT WIRE
YEL WIRE
