Radio circuit, w/ navigation w/o amplifier for Volkswagen Touareg II (2010-2014)
Radio circuit, w/ navigation w/o amplifier (1 of 2)
ANTENNA
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CD/DVD CHANGER CIRCUIT
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
EXTERNAL AUDIO SOURCE CONNECTION
FRONT INFORMATION DISPLAY CONTROL HEAD
FUSE 47
FUSE 51
FUSE PANEL C
GPS ANTENNA
GRN WIRE
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT ANTENNA MODULE
LEFT FRONT MICROPHONE
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RADIO ANTENNA 2
RED/YEL WIRE
RIGHT ANTENNA MODULE
RIGHT END OF DASH)
ROOF ANTENNA
SATELLITE TUNER ANTENNA
VIO WIRE
WHT WIRE
YEL WIRE
Radio circuit, w/ navigation w/o amplifier (2 of 2)
BRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
GRY/VIO WIRE
LEFT FRONT BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR BASS SPEAKER
LEFT REAR TREBLE SPEAKER
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/ WIRE
RADIO/NAVIGATION CONTROL MODULE
RED/YEL WIRE
RIGHT END OF DASH)
RIGHT FRONT BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR BASS SPEAKER
RIGHT REAR TREBLE SPEAKER
VIO WIRE
WHT WIRE
YEL WIRE
