Power top/sunroof circuit for Volkswagen Touareg II (2010-2014)

Power top/sunroof circuit

Get access

BLK WIRE BLK/BRN WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE FUSE PANEL B (LEFT END OF DASH) ILL POWER SUNROOF CONTROL MODULE (FRONT CENTER OF SUNROOF) RED WIRE RED/GRN WIRE RED/YEL WIRE ROOF SHADE CONTROL MODULE (CENTER REAR OF ROOF) ROOF SHADE MOTOR SUNROOF MOTOR SUNROOF SWITCH VIO WIRE WHT WIRE
