Car Wiring Diagrams for Backrest release circuit for Volkswagen Touareg II (2010-2014)

BACKREST BACKREST RELEASE RELEASE MOTOR 1 MOTOR 2 BACKREST RELEASE CONTROL MODULE (RIGHT FRONT OF LUGGAGE COMPT) BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BUTTON 1 BUTTON 2 GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES FUSE PANEL B FUSE 6 (LEFT END OF DASH) PUSH BUTTON ILLUMINATION BULB BACKREST RELEASE BUTTON RED WIRE RED/GRN WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) VIO WIRE VIO/WHT WIRE WHT WIRE YEL/RED WIRE
