Steering column memory circuit for Volkswagen Touareg II (2010-2014)
Steering column memory circuit
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR)
FUSE (LEFT END OF DASH)
FUSE PANEL B
GRN WIRE
GRN/BLK WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
MEMORY SEAT POSITION 1 SWITCH
MEMORY SEAT POSITION 4 SWITCH
MOTOR: ON STEERING COLUMN)
POWER ADJUSTABLE STEERING COLUMN CONTROL MODULE (ON STEERING COLUMN)
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
SEAT MEMORY SWITCH
STEERING COLUMN ADJUSTMENT SWITCH
STEERING COLUMN AXIAL ADJUSTMENT MOTOR/SENSOR (STEERING COLUMN AXIAL ADJUSTMENT
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
VIO/BRN WIRE
VIO/WHT WIRE
WHT WIRE
