Trailer tow circuit for Volkswagen Touareg II (2010-2014)
Trailer tow circuit
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EXTERIOR LAMPS CIRCUIT
FUSE
FUSE FUSE
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
TOWING RECOGNITION CONTROL MODULE (BEHIND LUGGAGE COMPT RIGHT SIDE TRIM PANEL)
TRAILER SOCKET (4-PIN)
TRAILER SOCKET (7-PIN)
YEL WIRE
