Cruise control circuit for Volkswagen Touareg II (2010-2014)

Cruise control circuit (1 of 2)

Get access

1 2 3 4 5 PNK WIRE 3.0L TURB0 DIESEL 3.6L 3.0L TURBO DIESEL 3.0L HYBRID 3.6L, 3.0L HYBRID ACCELERATOR PEDAL POSITION SENSOR 2 BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLU/VIO WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL INDICATOR LAMP ENGINE CONTROL MODULE (ECM) (IN RIGHT PLENUM) FUSE 10 FUSE 9 FUSE/ PANEL RELAY GRN WIRE HOT W/ POWER SUPPLY RELAY (TERMINAL 30) ENERGIZED INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE ORG/BLK WIRE ORG/BRN WIRE ORG/VIO WIRE PNK WIRE RED/GRN WIRE RED/YEL WIRE THROTTLE VALVE CONTROL MODULE (3.0L TURBO DIESEL) (ON THROTTLE BODY) THROTTLE VALVE CONTROL MODULE (EXCEPT 3.0L TURBO DIESEL) (ON THROTTLE BODY) VIO/YEL WIRE WHT/BLU WIRE WHT/VIO WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/GRY WIRE

Get access

1 2 3 4 5 PNK WIRE ADAPTIVE CRUISE CONTROL DISTANCE SELECTOR SWITCH BLK WIRE BLK/RED WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (UNDER LEFT COMPUTER DATA LINES SYSTEM CRUISE CONTROL SET BUTTON CRUISE CONTROL SWITCH GRN WIRE INCREASE SPEED BUTTON LEFT MULTI-FUNCTION BUTTONS LEFT STEERING COLUMN SWITCH MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRN WIRE PNK WIRE RED/GRN WIRE RIGHT MULTI-FUNCTION BUTTONS SIDE OF DASH) SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE (TOP OF STEERING COLUMN) TEMPORARY REDUCE CRUISE SPEED CONTROL BUTTON DEACTIVATION BUTTON VIO WIRE
