Computer data lines circuit for Volkswagen Touareg II (2010-2014)

Computer data lines circuit (1 of 6)

Touareg Volkswagen II (2010-2014): Computer data lines circuit (1 of 6)

Get access

BLK/BLU WIRE BLU WIRE BRN WIRE CONNECTION, JUNCTION BOX 3 (IN HSB BATTERY BOX, UNDER DRIVER'S SEAT) DATA BUS ON BOARD DIAGNOSTIC INTERFACE (LEFT END OF DASH) DIAGNOSTIC CONNECTION DISTANCE REGULATION CONTROL MODULE 2 (LEFT SIDE OF FRONT BUMPER) FUSE 47 FUSE PANEL GENERATOR GRN WIRE GRY/VIO WIRE GRY/WHT WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED IMAGE PROCESSING CONTROL MODULE (IF EQUIPPED) (UNDER FRONT PASSENGER'S SEAT) NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/RED WIRE ORG/VIO WIRE PNK WIRE RED/WHT WIRE RED/YEL WIRE VEHICLE POSITIONING SYSTEM CONTROL MODULE (IF EQUIPPED) VOLTAGE STABILIZER (IF EQUIPPED) (RIGHT SIDE OF DASH)

Computer data lines circuit (2 of 6)

Touareg Volkswagen II (2010-2014): Computer data lines circuit (2 of 6)

Get access

3.0L DIESEL ENGINE 3.6L GASOLINE ENGINE 3.0L HYBRID AIR BAG CONTROL MODULE (UNDER CENTER CONSOLE) BATTERY REGULATION CONTROL MODULE (LEFT FRONT OF HYBRID BATTERY UNIT) BLK WIRE BLK/BLU WIRE BRN WIRE BRN/YEL WIRE DECOUPLER PRESSURE ACTUATOR (BEHIND LEFT FRONT WHEEL HOUSING LINER) DIGITAL SOUND SYSTEM CONTROL MODULE (IF EQUIPPED) (TOP OF LEFT "D" PILLAR) ELECTRICAL DRIVE CONTROL MODULE ELECTRICAL DRIVE POWER, CONTROL MODULE ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE (ON STEERING COLUMN) ENGINE CONTROL MODULE (IN RIGHT PLENUM) EXTERNAL MULTIMEDIA DEVICE INTERFACE (IF EQUIPPED) FUSE 23 (LEFT END OF DASH) FUSE PANEL B GRY/VIO WIRE HOT AT ALL TIMES IGNITION SWITCH KEY LOCK SOLENOID/ IGNATION/STARTER SWITCH NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/RED WIRE ORG/VIO WIRE ORG/WHT WIRE RED/WHT WIRE RED/YEL WIRE TRANSMISSION CONTROL MODULE (UNDER FRONT PASSENGER'S SEAT) WHT/YEL WIRE

Computer data lines circuit (3 of 6)

Touareg Volkswagen II (2010-2014): Computer data lines circuit (3 of 6)

Get access

A/C COMPRESSOR CONTROL MODULE (3.0L HYBRID) (ON A/C COMPRESSOR UNIT) ABS CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) AXLE DIFFERENTIAL LOCK CONTROL MODULE (IF EQUIPPED) CORNERING LAMP, HEADLAMP RANGE CONTROL MODULE (UNDER CENTER OF DASH) DIFFERENTIAL CONTROL MODULE (IF EQUIPPED) (UNDER FRONT PASSENGER'S SEAT) GRY/VIO WIRE NCA WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/RED WIRE ORG/VIO WIRE PITCH RATE SENSOR (IF EQUIPPED) (UNDER RIGHT REAR SEAT) POWER STEERING CONTROL MODULE (3.0L HYBRID) (FRONT OF LEFT FRONT WHEELWELL) STEERING COLUMN ELECTRONICS CONTROL MODULE (TOP OF STEERING COLUMN)

Computer data lines circuit (4 of 6)

Touareg Volkswagen II (2010-2014): Computer data lines circuit (4 of 6)

Get access

BRN WIRE DRIVER DOOR CONTROL MODULE (IN DRIVER DOOR) DRIVER SEAT ADJUSTMENT CONTROL MODULE (IF EQUIPPED) (UNDER DRIVER'S SEAT) FRONT PASSENGER DOOR CONTROL MODULE (IN PASSENGER'S FRONT DOOR) GRN WIRE GRY/VIO WIRE LEFT REAR DOOR CONTROL MODULE (IF EQUIPPED) (LEFT REAR DOOR) NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE REAR LID CONTROL MODULE (CENTER OF REAR LID) RIGHT REAR DOOR CONTROL MODULE (IF EQUIPPED) (RIGHT REAR DOOR) TRAILER SETUP VIO WIRE VIO/WHT WIRE WHT WIRE

Computer data lines circuit (5 of 6)

Touareg Volkswagen II (2010-2014): Computer data lines circuit (5 of 6)

Get access

AIR QUALITY SENSOR COMFORT SYSTEM CENTRAL CONTROL MODULE (UNDER LEFT SIDE OF DASH) ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE (ON STEERING COLUMN) FRESH AIR BLOWER GARAGE DOOR OPENER CONTROL HEAD (IF EQUIPPED) GARAGE DOOR OPENER CONTROL MODULE (CENTER OF FRONT GRILLE) GRN WIRE GRY/BRN WIRE GRY/VIO WIRE HIGH PRESSURE SENSOR IGNITION/STARTER SWITCH/IGNITION SWITCH KEY LOCK SOLENOID INTERIOR MONITORING SENSOR LEFT FRONT SEAT VENTILATION CONTROL MODULE (IF EQUIPPED) (UNDER LEFT FRONT SEAT) MODULE (UNDER LEFT SIDE OF DASH) NCA WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE POWER SUNROOF CONTROL MODULE (FRONT CENTER OF ROOF) RAIN/LIGHT RECOGNITION REAR FRESH AIR BLOWER RIGHT INDIRECT VENTILATION DOOR CONTROL MOTOR ROOF SHADE CONTROL MODULE (CENTER REAR OF ROOF) SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL VIO/GRN (OR GRN/ WHT) WIRE VIO/GRN WIRE VIO/WHT WIRE WHT (OR GRN) WIRE WHT/BLU WIRE WINDSHIELD WIPER MOTOR (CENTER REAR OF ENGINE COMPT, UNDER COWL TRIM)

Computer data lines circuit (6 of 6)

Touareg Volkswagen II (2010-2014): Computer data lines circuit (6 of 6)

Get access

AUXILIARY AIR HEATER CONTROL MODULE (IF EQUIPPED) BRN WIRE CLIMATRONIC CONTROL MODULE (IN FRONT A/C DISPLAY CONTROL HEAD) DIGITAL SOUND SYSTEM CONTROL MODULE (IF EQUIPPED) (TOP OF LEFT "D" PILLAR) DVD CHANGER (IF EQUIPPED) GRY WIRE GRY/VIO WIRE HEATER CONTROL MODULE (IF EQUIPPED) (LEFT FRONT WHEELWELL) INFORMATION ELECTRONICS CONTROL MODULE 1 (IF EQUIPPED) INSTRUMENT CLUSTER CONTROL MODULE NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/VIO WIRE PARKING AID CONTROL MODULE (IF EQUIPPED) (UNDER LEFT SIDE OF DASH) RADIO RADIO/ NAVIGATION DISPLAY UNIT CONTROL MODULE (IF EQUIPPED) REAR A/C DISPLAY CONTROL HEAD (IF EQUIPPED) RIGHT TEMPERATURE DOOR MOTOR (RIGHT SIDE OF HVAC UNIT) TIRE PRESSURE MONITORING CONTROL MODULE (IF EQUIPPED) (UNDER LEFT SIDE OF DASH) TV TUNER (IF EQUIPPED) VIO WIRE VIO/WHT WIRE
