Access/start circuit for Volkswagen Touareg II (2010-2014)

Access/start circuit

Get access

ACCESS/START AUTHORIZATION BUTTON ACCESS/START AUTHORIZATION CONTROL MODULE BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE COMFORT SYSTEM CENTARL CONTROL MODULE (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FUSE 31 OF DASH) FUSE 33 FUSE 36 FUSE PANEL C (RIGHT END GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT ACCESS/START AUTHORIZATION ANTENNA LEFT FRONT EXTERIOR DOOR HANDLE TOUCH SENSOR (ON LEFT FRONT DOOR HANDLE) LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR (ON LEFT REAR DOOR HANDLE) LUGGAGE COMPARTMENT ACCESS/START SYSTEM ANTENNA (CENTER REAR OF LUGGAGE COMPT) ORG/BRN WIRE ORG/GRN WIRE RED/GRN WIRE RED/YEL WIRE RIGHT ACCESS/START AUTHORIZATION ANTENNA RIGHT FRONT EXTERIOR DOOR HANDLE TOUCH SENSOR (ON RIGHT FRONT DOOR HANDLE) RIGHT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR (ON RIGHT REAR DOOR HANDLE) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA 1 VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE WHT WIRE
