Volkswagen Touareg II (2010-2014) external audio source connection shield Wiring diagram
This page shows the only wiring diagram for the component.external audio source connection shield, which is found in the car Volkswagen Touareg II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram external audio source connection shield (1 of 1)
3.0L HYBRID
3.0L TURBO DIESEL
3.6L
AUTOMATIC GLOW TIME CONTROL MODULE
BATTERY MONITORING CONTROL MODULE
BATTERY REGULATION CONTROL MODULE
BLK WIRE
BRN WIRE
BRN/GRN WIRE
CELL PHONE OPERATING ELECTRONICS CONTROL MODULE
DIGITAL SOUND SYSTEM CONTROL MODULE
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS
ENGINE CONTROL MODULE
ENGINE COOLANT CIRCULATION PUMP 2
EXTERNAL AUDIO SOURCE CONNECTION SHIELD
FRONT INFORMATION DISPLAY CONTROL HEAD
HEADLAMP WASHER PUMP
HIGH TEMPERATURE CIRCUIT COOLANT PUMP
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
IGNITION COIL 5 W/ POWER OUTPUT STAGE
IGNITION COIL 6 W/ POWER OUTPUT STAGE
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT FOG LAMP
LEFT WASHER NOZZLE HEATER
LOW TEMPERATURE CIRCUIT COOLANT PUMP
LOW TEMPERATURE REDUCED CIRCUIT OIL PRESSURE COOLANT PUMP SWITCH
OIL LEVEL THERMAL SENSOR
OIL PRESSURE SWITCH
RADIO
RADIO SHIELD
REDUCED OIL PRESSURE SWITCH
RIGHT END OF DASH)
RIGHT FRONT FOG LAMP
RIGHT FRONT HEADLAMP
RIGHT WASHER NOZZLE HEATER
SECONDARY AIR INJECTION PUMP MOTOR
THREE-PHASE CURRENT DRIVE
THROTTLE VALVE CONTROL MODULE
Go to component -> Ground distribution circuit (5 of 5) -> EXTERNAL AUDIO SOURCE CONNECTION SHIELD
