Radio/navigation circuit, rns2 with 8-channel for Volkswagen Touareg I facelift (2006-2010)

ANTENNA AMPLIFIER BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CD CHANGER COMPUTER DATA LINES SYSTEM FUSE FUSE PANEL C GRN WIRE GRY WIRE HOT AT ALL TIMES NAVIGATION SYSTEM ANTENNA (RIGHT FRONT OF ENGINE COMPT) NCA WIRE OPERATING ELECTRONICS, TELEPHONE CONTROL MODULE ORG/BRN WIRE ORG/VIO WIRE RADIO/NAVIGATION DISPLAY CONTROL MODULE REAR WINDOW ANTENNA REAR WINDOW ANTENNA 2 RED WIRE RED/YEL WIRE TELEPHONE MICROPHONE VIO/GRN WIRE W/ SDARS TUNER W/O SDARS TUNER WHT WIRE WIPER MOTOR CONTROL MODULE YEL WIRE

AIRBAG SPIRAL SPRING/RETURN SPRING (W/ SLIP RING) BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DIGITAL SATELLITE RADIO TUNER (IF EQUIPPED) EXTERNAL AUDIO SOURCE CONNECTOR FUSE FUSE PANEL B FUSE PANEL C GRN WIRE GRY WIRE HOT AT ALL TIMES INCREASE VOLUME BUTTON MUTE SWITCH BUTTON NCA WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE RADIO/NAVIGATION DISPLAY CONTROL MODULE REAR VIEW CAMERA SYSTEM CONTROL MODULE RED WIRE RED/GRN WIRE RED/YEL WIRE REDUCE VOLUME BUTTON RIGHT MULTI-FUNCTION BUTTONS SATELLITE TUNER ANTENNA STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE W/ EXTERNAL AUDIO SOURCE CONNECTOR W/ REAR VIEW CAMERA W/ SDARS TUNER W/O REAR VIEW CAMERA YEL WIRE

AMPLIFIER (RIGHT SIDE OF CARGO AREA) BLU WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/YEL WIRE CENTER MIDRANGE SPEAKER COMPUTER DATA LINES SYSTEM FUSE FUSE PANEL C GRY WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR MIDRANGE SPEAKER NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RED WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR MIDRANGE SPEAKER WHT/YEL WIRE
