Car Wiring Diagrams for Electronic compass circuit for Volkswagen Touareg I facelift (2006-2010)

BRN WIRE COMPUTER DATA LINES SYSTEM HOT AT ALL TIMES FUSE PANEL C FUSE INSTRUMENT CLUSTER ORG/BLK WIRE ORG/BRN WIRE ORG/VIO WIRE RED/YEL WIRE ROOF DISPLAY UNIT VEHICLE POSITION RECOGNITION CONTROL MODULE
