Adaptive front lighting circuit for Volkswagen Touareg I facelift (2006-2010)

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/WHT WIRE BLL BRN WIRE CAN L COMPUTER DATA LINES SYSTEM (BEHIND LEFT SIDE OF INSTRUMENT CLUSTER) DYNAMIC CORNERING LIGHT MOTOR (IF EQUIPPED) FUSE FUSE FUSE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE HEADLAMP BEAM ADJUSTMENT MOTOR HEADLAMP POWER OUTPUT STAGE HEADLIGHT DIMMER/FLASHER SWITCH/PARK LIGHT SWITCH HIGH INTENSITY GAS DISCHARGE LAMP HIGH INTENSITY GAS DISCHARGE LAMP CONTROL MODULE HOT AT ALL TIMES FUSE PANEL B HOT AT ALL TIMES FUSE PANEL C HOT W/ POWER SUPPLY RELAY ENERGIZED LEFT HEADLAMP ASSEMBLY ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE PARK RED/GRN WIRE REFLECTOR ADJUSTMENT SOLENOID RIGHT FRONT FOG LIGHT LEFT FRONT FOG LIGHT SWIVEL MODULE POSITION SENSOR (IF EQUIPPED) TURN VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) VIO/BLK WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE

BLK/BLU WIRE BLK/GRN WIRE BLL BLU WIRE BRN WIRE CAN L COMPUTER DATA LINES SYSTEM DYNAMIC CORNERING LIGHT MOTOR (IF EQUIPPED) FOG LAMP SWITCH GRN WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HEADLAMP BEAM ADJUSTMENT MOTOR HEADLAMP POWER OUTPUT STAGE HEADLAMP RANGE/ CORNERING LAMP CONTROL MODULE HEADLIGHT SWITCH LIGHTS HIGH INTENSITY GAS DISCHARGE LAMP HIGH INTENSITY GAS DISCHARGE LAMP CONTROL MODULE LIGHT SWITCH ORG/BLK WIRE ORG/BRN WIRE PARK REFLECTOR ADJUSTMENT SOLENOID RIGHT HEADLAMP ASSEMBLY SWIVEL MODULE POSITION SENSOR (IF EQUIPPED) TURN VIO/BLK WIRE WHT WIRE WHT/BRN WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE
