Volkswagen Touareg I (2002-2006) front axle stabilizer decoupling sensor Wiring diagram
This page shows the only wiring diagram for the component.front axle stabilizer decoupling sensor, which is found in the car Volkswagen Touareg I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front axle stabilizer decoupling sensor (1 of 1)
2004 EARLY PROD
BLK WIRE
BLK/BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
ENERGIZED BY ACCESS/START CONTROL MODULE
EXCEPT 2004 EARLY PROD
FRONT AXLE STABILIZER DECOUPLING SENSOR
FUSE
FUSE PANEL B
FUSE PANEL C
FUSE PANEL D
GRN/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/VIO WIRE
REAR AXLE STABILIZER DECOUPLING SENSOR
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
STABILIZER DECOUPLING CONTROL MODULE
STABILIZER HYDRAULIC CONTROL UNIT
STABLIZER DECOUPLING CONTROL MODULE, BUTTON
VIO/BRN WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/ AIR SUSPENSION
W/O AIR SUSPENSION
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Stabilizer circuit -> FRONT AXLE STABILIZER DECOUPLING SENSOR
