Trunk & fuel door release circuit for Volkswagen Tiguan II facelift (2020-2024)

BLK/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE FUSE 31 FUSE PANEL C GRN/YEL WIRE GRY/YEL WIRE HOT AT ALL TIMES LUGGAGE COMPARTMENT REAR LID LOCK BUTTON ORG/BRN WIRE ORG/GRN WIRE REAR LID CENTRAL LOCKING SYSTEM MOTOR REAR LID CONTACT SWITCH REAR LID CONTROL MODULE REAR LID MOTOR 1 (TOP LEFT OF TAILGATE) REAR LID MOTOR 1 SENSOR REAR LID REMOTE RELEASE BUTTON RED/WHT WIRE VIO WIRE VIO/BLK WIRE VIO/WHT WIRE VIO/YEL WIRE W/ POWER REAR LID OPENING W/O TRAILER HITCH WHT WIRE YEL/VIO WIRE

BLK WIRE BLK/BLU WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM EARLY PRODUCTION FUSE 18 FUSE PANEL C GRN WIRE GRN/BLU WIRE GRN/GRY WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LATE PRODUCTION LEFT COUPLING POINT ON REAR LID NAVIGATION SYSTEM NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRN WIRE REAR LID AMBIENT LAMP 1 REAR LID CLOSING AID (LEFT SIDE OF TAILGATE) REAR LID CLOSING AID MOTOR REAR LID HANDLE REAR LID HANDLE RELEASE BUTTON REAR LID WARNING BUZZER REAR PERIPHERAL CAMERA REAR VIEW CAMERA RED/BLU WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/WHT WIRE WHT WIRE YEL/GRN WIRE YEL/VIO WIRE

ACCESS/START SYSTEM INTERFACE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM FUEL FILLER DOOR LOCK MOTOR FUEL FILLER DOOR UNLOCK NCA WIRE ORG/BRN WIRE ORG/GRN WIRE POWER REAR LID OPENING CONTROL MODULE POWER REAR LID OPENING SENSOR POWER REAR LID OPENING SENSOR 2 RED/BLU WIRE RED/YEL WIRE RIGHT COUPLING POINT IN LUGGAGE COMPARTMENT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BRN WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE
