Volkswagen Tiguan II facelift (2020-2024) Courtesy lamps circuit
Courtesy lamps circuit (1 of 3)
BLK/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DOOR CONTACT SWITCH
FUSE 24
FUSE PANEL C
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
LEFT FRONT FOOTWELL LAMP
LEFT REAR DOOR COUPLING POINT
LEFT REAR DOOR LOCK UNIT
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLU WIRE
RIGHT FRONT FOOTWELL LAMP
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR DOOR LOCK UNIT
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
Courtesy lamps circuit (2 of 3)
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/VIO WIRE
COUPLING POINT ON ROOF
FRONT INTERIOR LAMP
FRONT INTERIOR LAMP BUTTON
FRONT INTERIOR LAMP DOOR CONTACT SWITCH
GLOVE COMPARTMENT LAMP
GLOVE COMPARTMENT LAMP SWITCH
GRY WIRE
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR REAR VIEW MIRROR
LEFT FRONT READING LAMP
LEFT FRONT READING LAMP BUTTON
LEFT REAR INTERIOR LAMP
LEFT REAR INTERIOR LAMP (W/ SUNROOF)
LEFT REAR READING LAMP
LEFT REAR READING LAMP SWITCH
LUGGAGE COMPARTMENT LAMP
REAR INTERIOR LAMP BUTTON
RED/BLU WIRE
RED/WHT WIRE
RIGHT FRONT READING LAMP
RIGHT FRONT READING LAMP BUTTON
RIGHT REAR INTERIOR LAMP
RIGHT REAR READING LAMP
RIGHT REAR READING LAMP SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WHT WIRE
Courtesy lamps circuit (3 of 3)
BLK/BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DOOR CONTACT SWITCH
DRIVER DOOR CONTROL MODULE (IN DRIVER'S DOOR)
DRIVER DOOR LOCK UNIT
DRIVER ENTRY LAMP
DRIVER EXTERIOR REAR VIEW MIRROR
DRIVER VANITY MIRROR LAMP
DRIVER VANITY MIRROR LAMP CONTACT SWITCH
FLASH LIGHT
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER DOOR LOCK UNIT
FRONT PASSENGER ENTRY LAMP
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FRONT PASSENGER VANITY MIRROR LAMP
FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH
FUSE 25
FUSE 39
FUSE PANEL C
GRN WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT ENTRY LAMP
MEMORY SYSTEMS
RED/BLU WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT ENTRY LAMP
RIGHT REAR INTERIOR LAMP (W/ SUNROOF)
RIGHT REAR READING LAMP
RIGHT REAR READING LAMP SWITCH
W/ PERIPHERAL CAMERA
W/O PERIPHERAL CAMERA
WHT WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
