Heated mirrors circuit for Volkswagen Tiguan II facelift (2020-2024)
Heated mirrors circuit
BLK/BLU WIRE
BLK/RED WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
EXTERIOR REAR VIEW MIRROR ADJUSTER
EXTERIOR REAR VIEW MIRROR HEATING SWITCH
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 25
FUSE 39
FUSE PANEL C
GRN WIRE
HEATER
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
MEMORY SYSTEMS
RIGHT FRONT DOOR COUPLING POINT
VIO WIRE
W/ PERIPHERAL CAMERA
W/O MEMORY W/ MEMORY
W/O PERIPHERAL CAMERA
WHT WIRE
YEL WIRE
