Automatic a/c circuit for Volkswagen Tiguan II facelift (2020-2024)

AIR QUALITY SENSOR BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BOTTOM RIGHT COUPLING POINT IN INTERIOR BRN WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM DEFROSTER DOOR FOOTWELL VENT TEMPERATURE SENSOR FUSE 14 FUSE 29 FUSE 34 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/RED WIRE GRY/WHT WIRE HEATED DRIVER SEAT INDICATOR LAMP HEATED FRONT PASSENGER SEAT INDICATOR LAMP HEATER, A/C CONTROLS HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT FRONT TEMPERATURE CONTROL DOOR LEFT SEAT HEATING BUTTON ORG/BRN WIRE ORG/GRN WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE REFRIGERANT CIRCUIT PRESSURE SENSOR RIGHT SEAT HEATING BUTTON VIO WIRE VIO/BLK WIRE VIO/WHT WIRE VIO/YEL WIRE W/ ENGINE REMOTE START W/O ENGINE REMOTE START WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/VIO WIRE

AIR RECIRCULATION DOOR (TOP RIGHT END OF HVAC UNIT) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/VIO WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM EVAPORATOR TEMPERATURE SENSOR FRESH AIR BLOWER FRESH AIR BLOWER CONTROL MODULE GRN WIRE GRN/BLK WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/RED WIRE GRY/WHT WIRE INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER NCA WIRE ORG/BRN WIRE ORG/GRN WIRE OUTSIDE AIR TEMPERATURE SENSOR REAR TEMPERATURE CONTROL DOOR MOTOR RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT TEMPERATURE CONTROL DOOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/BLK WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT/BLU WIRE WINDSHIELD WASHER FLUID LEVEL SENSOR YEL/BLK WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/VIO WIRE

A/C CLUTCH RELAY A/C COMPRESSOR REGULATOR VALVE AIR DISTRIBUTION DOOR (TOP LEFT OF HVAC UNIT) BLK WIRE BLU/GRN WIRE BLU/VIO WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE BRN/BLK WIRE BRN/VIO WIRE COMPRESSOR MAGNETIC CLUTCH ENGINE COOLANT LEVEL SENSOR FUSE 7 FUSE PANEL C GRN/BLK WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/YEL WIRE HOT AT ALL TIMES LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT REAR A/C DISPLAY CONTROL HEAD REAR VENT TEMPERATURE SENSOR RED/BLK WIRE RED/YEL WIRE RIGHT VENT TEMPERATURE SENSOR SUNLIGHT PHOTO SENSOR VIO WIRE VIO/BLK WIRE VIO/RED WIRE VIO/WHT WIRE WHT/BLU WIRE YEL/BLK WIRE YEL/VIO WIRE

AUXILIARY HEATER HEATING ELEMENT (LEFT SIDE OF HVAC UNIT) BLK WIRE BLK/RED WIRE BLK/YEL WIRE BOTTOM RIGHT COUPLING POINT IN INTERIOR BRN WIRE ENGINE CONTROLS SYSTEM FUSE 11 FUSE 12 FUSE 24 FUSE PANEL B GRN/VIO WIRE GRN/YEL WIRE HIGH HEAT OUTPUT RELAY LEFT VENT TEMPERATURE SENSOR LOW HEAT OUTPUT RELAY RED/BLK WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 VIO/RED WIRE

BLK WIRE BLK/RED WIRE BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET ENGINE/MOTOR CONTROL MODULE FUSE 17 FUSE 4 FUSE 5 FUSE PANEL A FUSE PANEL B HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED NCA WIRE ORG/BLK WIRE ORG/BRN WIRE RADIATOR FAN RADIATOR FAN (BEHIND RADIATOR) RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE RED/BLK WIRE RED/GRN WIRE VIO/RED WIRE YEL/VIO WIRE
