Volkswagen Tiguan II facelift (2020-2024) driving profile selection indicator lamp Wiring diagrams

BLK WIRE BLK/VIO WIRE BLU WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BOTTOM RIGHT COUPLING POINT IN INTERIOR BRN WIRE CENTER CONSOLE SWITCH MODULE 1 COMPUTER DATA LINES SYSTEM DRIVING PROFILE SELECTION BUTTON DRIVING PROFILE SELECTION CONTROL HEAD DRIVING PROFILE SELECTION INDICATOR LAMP ELECTRONIC DAMPING CONTROL MODULE FUSE 52 FUSE 8 FUSE PANEL C GRN/GRY WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT BODY ACCELERATION SENSOR LEFT FRONT DAMPING ADJUSTMENT VALVE LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT REAR DAMPING ADJUSTMENT VALVE LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE REAR BODY ACCELERATION SENSOR RED WIRE RED/BLU WIRE RIGHT FRONT BODY ACCELERATION SENSOR RIGHT FRONT DAMPING ADJUSTMENT VALVE RIGHT FRONT LEVEL CONTROL SYSTEM SENSOR RIGHT REAR DAMPING ADJUSTMENT VALVE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLU WIRE VIO/GRN WIRE VIO/YEL WIRE WHT/GRY WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

BLK/YEL WIRE BRN WIRE CELLULAR TELEPHONE PREPARATION CONTROL HEAD CENTER CONSOLE CENTER CONSOLE SWITCH MODULE 1 CENTER CONSOLE SWITCH MODULE 2 COMPUTER DATA LINES SYSTEM DRIVER SIDE REAR POWER WINDOW BUTTON DRIVER SIDE REAR WINDOW REGULATOR MOTOR DRIVING PROFILE SELECTION INDICATOR LAMP EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE FRONT INTERIOR LAMP FUSE 24 FUSE 34 FUSE 8 FUSE PANEL C GRY WIRE GRY/BLU WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT REAR DOOR COUPLING POINT LIGHT SWITCH ORG/BRN WIRE ORG/GRN WIRE OVERHEAD CONSOLE PARKING BRAKE BUTTON PUSH BUTTON ILLUMINATION BULB RED WIRE RED/BLU WIRE RED/YEL WIRE ROOF COUPLING POINT ROTARY LIGHT SWITCH SELECTOR MECHANISM USB CHARGING SOCKET 1 USB CONNECTION 1 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE WINDSHIELD PROJECTION CONTROL UNIT WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
