Volkswagen Tiguan II facelift (2020-2024) coupling point on right rear bumper Wiring diagram
This page shows the only wiring diagram for the component.coupling point on right rear bumper, which is found in the car Volkswagen Tiguan II facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coupling point on right rear bumper (1 of 1)
BLK/YEL WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CENTER CONSOLE SWITCH MODULE 2
COUPLING POINT ON RIGHT REAR BUMPER
GRY WIRE
LEFT REAR CENTER PARKING AID SENSOR
LEFT REAR PARALLEL PARKING ASSISTANCE SENSOR
LEFT REAR PARKING AID SENSOR
PARALLEL PARKING ASSISTANCE BUTTON
PARALLEL PARKING ASSISTANCE IND LAMP
PARKING AID BUTTON
PARKING AID IND LAMP
PUSH BUTTON ILLUMINATION BULB
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT REAR CENTER PARKING AID SENSOR
RIGHT REAR PARALLEL PARKING ASSISTANCE SENSOR
RIGHT REAR PARKING AID SENSOR
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/WHT WIRE
Go to component -> Parking assistant circuit (2 of 2) -> COUPLING POINT ON RIGHT REAR BUMPER
