Radio circuit, w/ amplifier & central speaker for Volkswagen Tiguan II (2016-2020)

ANTENNA BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COMPUTER DATA COMPUTER DATA LINES SYSTEM FM FREQUENCY FILTER (NEGATIVE WIRE) FM FREQUENCY FILTER (POSITIVE WIRE) FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 10 FUSE 12 FUSE 16 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRN/VIO WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LINES SYSTEM MULTIMEDIA SYSTEM CONTROL HEAD NAVIGATION SYSTEM NAVIGATION SYSTEM (EMERGENCY CALL CIRCUIT) NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/VIO WIRE RADIO ANTENNA 2 REAR WINDOW DEFOGGER RED/BLU WIRE VIO WIRE VIO/GRN WIRE W/ EMERGENCY CALL W/O EMERGENCY CALL WHT WIRE WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BRN WIRE

AM FREQUENCY FILTER BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA (IF EQUIPPED) EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE EXTERNAL AUDIO SOURCE CONNECTION FUSE 53 FUSE PANEL C GRN WIRE GRN/VIO WIRE GRY WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT COUPLING POINT ON REAR LID NAVIGATION SYSTEM CONTROL MODULE (IF EQUIPPED) NCA WIRE ORG/ WIRE ORG/BRN WIRE REAR WINDOW DEFOGGER RELAY RED/BLU WIRE RED/WHT WIRE TELEPHONE MICROPHONE VIO/GRN WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE

BLK WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/RED WIRE BRN/YEL WIRE CENTER SPEAKER FUSE 43 FUSE PANEL C GRN WIRE GRY/BLU WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT TREBLE SPEAKER RED WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT TREBLE SPEAKER W/ PERIPHERAL CAMERA W/O PERIPHERAL CAMERA WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YEL/BLU WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/RED WIRE BRN/YEL WIRE DIGITAL SOUND SYSTEM CONTROL MODULE (UNDER DRIVER'S SEAT) GRN WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE ORG/ WIRE RED WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE TV TUNER (UNDER FRONT PASSENGER'S SEAT) WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BLU WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE GPS ANTENNA GRN WIRE GRN/YEL WIRE GRY/BRN WIRE GRY/RED WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR TREBLE SPEAKER LTE ANTENNA 1 (IF EQUIPPED) LTE ANTENNA 2 (IF EQUIPPED) ORG/ WIRE RED/BLU WIRE RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR TREBLE SPEAKER WHT WIRE WHT/YEL WIRE
