Volkswagen Tiguan I facelift (2011-2019) Shift interlock circuit

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/VIO WIRE BLU/YEL WIRE BRAKE LAMP SWITCH BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE FUSE 14 FUSE 20 FUSE 23 FUSE PANEL B FUSE PANEL C GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED HOT W/ TERMINAL 15 SUPPLY RELAY 2 ENERGIZED IGNITION SWITCH KEY LOCK SOLENOID ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE SELECTOR LEVER PARK POSITION LOCK SWITCH SHIFT LOCK SOLENOID STEERING COLUMN ELECTRONIC CONTROL MODULE TIPTRONIC SWITCH TRANSMISSION CONTROL MODULE TRANSMISSION RANGE DISPLAY VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE YEL WIRE
