Volkswagen Tiguan I facelift (2011-2019) Electronic compass circuit

BLU WIRE BRN WIRE COMPASS MAGNETIC FIELD SENSOR/ VEHICLE LOCATION RECOGNITION CONTROL MODULE COMPUTER DATA LINES SYSTEM FUSE 18 FUSE 23 FUSE 7 FUSE PANEL B FUSE PANEL C GRY/BLK WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT "C" PILLAR) MULTI-FUNCTION INDICATOR ORG/BRN WIRE ORG/VIO WIRE RED WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE VOLTAGE STABILIZER W/ START/ STOP SYSTEM W/O START/STOP SYSTEM W/ START/STOP SYSTEM YEL WIRE
