Volkswagen Tiguan I facelift (2011-2019) cell phone operating electronics control module/ telephone transceiver wiring diagram
This page shows the only wiring diagram for the component.cell phone operating electronics control module/ telephone transceiver, which is found in the car Volkswagen Tiguan I facelift (2011-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
cell phone operating electronics control module/ telephone transceiver wiring diagram (1 of 1)
ABS CONTROL MODULE
AIR BAG CONTROL MODULE
ALL-WHEEL DRIVE CONTROL MODULE (ON REAR DIFFERENTIAL)
AMPLIFIER
BRN WIRE
CELL PHONE OPERATING ELECTRONICS CONTROL MODULE/ TELEPHONE TRANSCEIVER
COMPASS MAGNETIC FIELD SENSOR/ VEHICLE LOCATION RECOGNITION CONTROL MODULE
DIGITAL SATELLITE RADIO TUNER
DRIVER ASSISTANCE SYSTEM FRONT CAMERA
ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE
ELECTRONIC DAMPING CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT)
EMERGENCY CALL MODULE, COMMUNICATION UNIT
ENGINE CONTROL MODULE (RIGHT CENTER OF ENGINE COMPT)
GRY WIRE
GRY/WHT WIRE
HEADLAMP RANGE/CORNERING LAMP CONTROL MODULE
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT HEADLAMP (W/ HID HEADLAMPS)
MULTIMEDIA SYSTEM CONTROL MODULE
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/VIO WIRE
PARALLEL PARKING ASSISTANCE/ PARKING AID CONTROL MODULE
POWER STEERING CONTROL MODULE
RADIO (W/O NAVIGATION)
RADIO/NAVIGATION DISPLAY CONTROL MODULE
RIGHT FRONT HEADLAMP (W/ HID HEADLAMPS)
TRANSMISSION CONTROL MODULE (TCM)
W/ NAVIGATION
Go to component -> Computer data lines circuit (2 of 2) -> CELL PHONE OPERATING ELECTRONICS CONTROL MODULE/ TELEPHONE TRANSCEIVER
