Volkswagen Tiguan I (2007-2011) Radio/navigation circuit, dynaudio

AM/FM ANTENNA BLK WIRE BLU WIRE BRN WIRE CD CHANGER (IF EQUIPED) COMPUTER DATA LINES SYSTEM DIGITAL SATELLITE RADIO TUNER (IF EQUIPED) (UNDER FRONT PASSENGER'S SEAT) FUSE 18 GPS GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL B (LEFT SIDE FUSE 8 OF ENGINE COMPT) NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RADIO/NAVIGATION DISPLAY CONTROL MODULE REAR DEFOGGER RELAY RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SAT SAT (IF EQUIPPED) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO/BLU WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FM FREQUENCY FILTER (-) GRN WIRE GRN/WHT WIRE GRY WIRE GRY/WHT WIRE HEATED REAR WINDOW/ RADIO ANTENNA 2 LEFT "C" PILLAR) LEFT FRONT BASS SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER LINES SYSTEM COMPUTER DATA NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RIGHT ANTENNA MODULE RIGHT FRONT BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR TREBLE SPEAKER WHT WIRE WHT/RED WIRE YEL WIRE
