Radio circuit, rcd 500/510 & without amplifier for Volkswagen Tiguan I (2007-2011)

AM/FM BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE CD CHANGER (IF EQUIPPED) COMPUTER DATA LINES SYSTEM DAB EXTERNAL AUDIO SOURCE FM FREQUENCY FILTER (-) FUSE 8 ENGINE COMPT) FUSE PANEL B (LEFT SIDE OF GRN WIRE GRY WIRE HOT AT ALL TIMES NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RADIO REAR WINDOW DEFOGGER RELAY RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO/BLU WIRE VIO/RED WIRE VIO/WHT WIRE W/ SATELLITE RADIO W/O SATELLITE RADIO WHT WIRE WHT/YEL WIRE YEL WIRE

AM/FM ANTENNA BLK WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DAB DIGITAL SATELLITE RADIO TUNER (IF EQUPPED) (UNDER FRONT PASSENGER'S SEAT) FM FREQUENCY FILTER (-) GRY WIRE HEATED REAR WINDOW/ RIGHT ANTENNA 2 LEFT "C" PILLAR) LEFT FRONT BASS SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT ANTENNA MODULE (IMPEDANCE TRANSFORMER) RIGHT FRONT BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR TREBLE SPEAKER SAT VIO/BLU WIRE VIO/RED WIRE VIO/WHT WIRE W/ RCD 300 W/ REAR SPEAKER WHT WIRE WHT/GRN WIRE WHT/RED WIRE
