Volkswagen Tiguan I (2007-2011) Electronic compass circuit

BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 23 FUSE PANEL HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT "C" PILLAR) MAGNETIC FIELD SENSOR FOR COMPASS (TOP LEFT REAR OF ROOF) MULTI-FUNCTION INDICATOR ORG/BRN WIRE ORG/VIO WIRE RED/BLU WIRE RED/WHT WIRE YEL WIRE
