Anti-theft circuit, early production for Volkswagen Tiguan I (2007-2011)

BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL LOCKING SAFE INDICATOR LAMP COMPUTER DATA LINE SYSTEM DRIVER'S DOOR CENTRAL LOCKING (SAFE) MOTOR DRIVER'S DOOR CENTRAL LOCKING LOCK UNIT DRIVER'S DOOR CENTRAL LOCKING LOCK UNIT (REAR OF DRIVER'S DOOR) DRIVER'S DOOR CENTRAL LOCKING SYSTEM MOTOR DRIVER'S DOOR CONTACT SWITCH DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S DOOR) DRIVER'S INTERIOR LOCK BUTTON DRIVER`S INSIDE DOOR HANDLE ILLUMINATION FRONT PASSENGER'S DOOR CENTRAL LOCKING (SAFE) MOTOR FRONT PASSENGER'S DOOR CENTRAL LOCKING SYSTEM MOTOR FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S DOOR) FRONT PASSENGER'S INSIDE DOOR HANDLE ILLUMINATION FUSE 45 GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES FUSE PANEL C (LOWER LEFT END OF DASH) NCA WIRE ORG/BRN WIRE ORG/GRN WIRE POWER WINDOWS SYSTEM RED/WHT WIRE RED/YEL WIRE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/RED WIRE YEL WIRE

BLK/GRY WIRE BRN WIRE BRN/WHT WIRE FUSE 22 FUSE 46 FUSE PANEL C (LOWER LEFT END OF DASH) HOT AT ALL TIMES LEFT REAR CENTRAL LOCKING (SAFE) MOTOR LEFT REAR CENTRAL LOCKING LOCK MOTOR LEFT REAR CENTRAL LOCKING LOCK UNIT LEFT REAR CENTRAL LOCKING LOCK UNIT (REAR OF LEFT REAR DOOR) LEFT REAR DOOR CONTACT SWITCH LEFT REAR DOOR CONTROL MODULE (IN LEFT REAR DOOR) RED/YEL WIRE RIGHT REAR CENTRAL LOCKING (SAFE) MOTOR RIGHT REAR CENTRAL LOCKING LOCK MOTOR RIGHT REAR CENTRAL LOCKING LOCK UNIT RIGHT REAR CENTRAL LOCKING LOCK UNIT (REAR OF RIGHT REAR DOOR) RIGHT REAR DOOR CONTACT SWITCH RIGHT REAR DOOR CONTROL MODULE (IN RIGHT REAR DOOR) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/VIO WIRE

ALARM HORN ANTI-THEFT IMMOBILIZER CONTROL MODULE ANTI-THEFT IMMOBILIZER READING COIL ANTI-THEFT IMMOBILIZER WARNING BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM ANTENNA COMFORT SYSTEM CENTRAL CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) COMPT) COMPUTER DATA LINES SYSTEM FRONT HOOD OPEN FRONT HOOD SWITCH FUEL TANK LID UNLOCK MOTOR FUSE 48 FUSE PANEL C (LOWER LEFT END OF DASH) GRN/YEL WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE INTERIOR MONITORING SENSOR LAMP LEFT "C" PILLAR) MODULE (BEHIND LEFT SIDE OF DASH) NCA WIRE ORG/BRN WIRE ORG/GRN WIRE PASSENGER COMPARTMENT MONITORING SWITCH REAR LID HANDLE UNLOCK SWITCH REAR LID LOCK UNIT (BOTTOM CENTER OF REAR LID DOOR) RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM VEHICLE ELECTRICAL SYSTEM CONTROL VIO WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE WARNING LAMP WHT WIRE YEL WIRE
