Volkswagen Tiguan I (2007-2011) tire pressure monitoring display ind lamp Wiring diagram

ABS CONTROL MODULE ABS HYDRAULIC UNIT AIR BAG CONTROL MODULE ANTI-SLIP IND ASR/ESP BUTTON BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BRAKE PAD WEAR IND LAMP BRAKE SYSTEM WARNING LAMP BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DOOR AJAR IND LAMP DRIVER'S DOOR CENTRAL LOCKING LOCK UNIT (REAR OF DRIVER'S DOOR) DRIVER'S DOOR CONTACT SWITCH DRIVER'S SAFETY BELT SWITCH DRIVER'S SIDE DOOR CONTROL MODULE (IN DRIVER'S DOOR) FRONT PASSENGER'S SAFETY BELT SWITCH FUSE FUSE 13 FUSE PANEL B (LEFT SIDE OF ENGINE COMPT) FUSE PANEL C (LOWER LEFT END OF DASH) FUSE 9 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 50) ENERGIZED INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE W/ DISPLAY UNIT LEFT FRONT BRAKE PAD WEAR SENSOR NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE PUSH- BUTTON ILLUMI- NATION RED WIRE RED/YEL WIRE SAFETY BELT WARNING LAMP SUPPLEMENTAL RESTRAINTS SYSTEM TIRE PRESSURE MONITORING DISPLAY BUTTON TIRE PRESSURE MONITORING DISPLAY IND LAMP VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO WIRE WARNING BUZZER WHT WIRE YEL WIRE
