Volkswagen Tiguan I (2007-2011) right headlamp power output stage Wiring diagram
This page shows the only wiring diagram for the component.right headlamp power output stage, which is found in the car Volkswagen Tiguan I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right headlamp power output stage (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
HEADLAMP DIMMER/ FLASHER SWITCH
HEADLIGHT RANGE/ CORNERING LAMP CONTROL MODULE (BEHIND GLOVE BOX)
HIGH BEAM IND
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT REAR LEVEL CONTROL SYSTEM SENSOR (LEFT REAR LOWER CONTROL ARM)
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
REAR FOG LAMP IND
RED WIRE
RED/BLK WIRE
RIGHT CORNERING LAMP
RIGHT DYNAMIC CORNERING LIGHT MOTOR
RIGHT HEADLAMP ASSEMBLY
RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR
RIGHT HEADLAMP POWER OUTPUT STAGE
RIGHT HIGH INTENSITY GAS DISCHARGE (HID) LAMP
RIGHT HIGH INTENSITY GAS DISCHARGE LAMP CONTROL MODULE
RIGHT LOW BEAM REFLECTOR MOTOR
RIGHT SWIVEL MODULE POSITION SENSOR
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (UNDER STEERING COLUMN)
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Headlights circuit, with xenon lamps (2 of 2) -> RIGHT HEADLAMP POWER OUTPUT STAGE
