Volkswagen Tiguan I (2007-2011) headlamp dimmer/ flasher switch Wiring diagrams

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOG LAMP SWITCH FUSE FUSE 23 FUSE PANEL C (LOWER LEFT END OF DASH) GRY WIRE GRY/YEL WIRE HEADLAMP DIMMER/ FLASHER SWITCH HIGH BEAM INDICATOR HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT FRONT FOG LAMP LEFT HEADLAMP ASSEMBLY LEFT LOW BEAM HEADLAMP LEFT HIGH BEAM HEADLAMP LIGHT SWITCH NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLU WIRE RIGHT FRONT FOG LAMP RIGHT HEADLAMP ASSEMBLY RIGHT HIGH BEAM HEADLAMP RIGHT LOW BEAM HEADLAMP STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (UNDER STEERING COLUMN) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GRN WIRE HEADLAMP DIMMER/ FLASHER SWITCH HEADLIGHT RANGE/ CORNERING LAMP CONTROL MODULE (BEHIND GLOVE BOX) HIGH BEAM IND INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT REAR LEVEL CONTROL SYSTEM SENSOR (LEFT REAR LOWER CONTROL ARM) ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE REAR FOG LAMP IND RED WIRE RED/BLK WIRE RIGHT CORNERING LAMP RIGHT DYNAMIC CORNERING LIGHT MOTOR RIGHT HEADLAMP ASSEMBLY RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP POWER OUTPUT STAGE RIGHT HIGH INTENSITY GAS DISCHARGE (HID) LAMP RIGHT HIGH INTENSITY GAS DISCHARGE LAMP CONTROL MODULE RIGHT LOW BEAM REFLECTOR MOTOR RIGHT SWIVEL MODULE POSITION SENSOR STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (UNDER STEERING COLUMN) WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
